Proposed Dock and Landscaping 333a Stewart Avenue Revised Site Plan

January 20, 2015Page 661 section

Revised site plan including landscaping details for the proposed project.

1 CALL TO ORDER
Revised September 22, 2014

Proposed Dock and Landscaping 333a Stewart Avenue

Site Plan

Scale: 1:100 Civic Address: 333a Stewart Avenue Legal Description: Lot B, Section 6, Esquimalt District, Plan VIP 81834 Revision: September 23, 2014 Designer: Bruce Wilkin Design (designers + builders)

Technical drawing including a detailed site plan and a site section for a proposed dock and landscaping project at 333a Stewart Avenue.
Technical drawing including a detailed site plan and a site section for a proposed dock and landscaping project at 333a Stewart Avenue.

Site Plan Annotations:

  • Helmcken Bay
  • Stewart Avenue
  • Existing concrete step - align with rock
  • Planter bed
  • Existing concrete walkway
  • Existing concrete steps faced with stone
  • New wood gate
  • Stone retaining wall
  • Timber stairs
  • Parallel stairway - faced with stone - concrete steps
  • Wood gate
  • Landing with bench
  • Existing garden to remain - planted with native species
  • Stone retaining wall
  • Existing shed
  • Existing landscaped area with native plantings
  • Existing retaining wall - repaired & aligned as necessary - faced with stone

Site Section

Scale: 1:100

Site Section Annotations:

  • House
  • Existing retaining walls planted with native species
  • Existing concrete path
  • New wood gate
  • Rock ramp
  • Floating dock
  • Water
Page 66
