Attachment 9. Condominium - First Floor Plan

March 20, 2012Page 401 section

Floor plan for the first residential level of the apartment building, including unit layouts and storage areas.

8.1a Development Permit No. 2011/13 - 301 Nursery Hill Drive
Sheet A42 bed + den unit types

Lake View Village - Proposed Residential Development

42 Condominium Units and 6 Townhomes 301 Nursery Hill Drive, View Royal, BC

Condominium - First Floor Plan - Scale 1:100

Architectural drawing of the first floor plan for a residential development at 301 Nursery Hill Drive, featuring seven residential suites, amenity space, and storage facilities.
Architectural drawing of the first floor plan for a residential development at 301 Nursery Hill Drive, featuring seven residential suites, amenity space, and storage facilities.
Unit Type Square Footage
2 bed + den 1025 s.f.
2 bed + den 1100 s.f.
2 bed + den 1025 s.f.
2 bed 1025 s.f.
2 bed 1025 s.f.
2 bed + den 1025 s.f.
2 bed 1025 s.f.

Common and Storage Areas

  • Residents Amenity Space
  • Residents scooter and bicycle storage
  • Residents Storage

Plan Dimensions and Annotations

  • 16.2
  • 22.97m
  • 21.90m
  • 22m
  • 28.82m
  • 23.49m
