Council Meeting/Documents/Attachment 13. Townhouse Floor Plans
Appendix

Attachment 13. Townhouse Floor Plans

March 20, 2012Page 441 section

Detailed floor plans for the six proposed townhouse units across two separate buildings.

8.1a Development Permit No. 2011/13 - 301 Nursery Hill Drive
Sheet A8Lower, Main, and Upper level layouts

Lake View Village - Proposed Residential Development

42 Condominium Units and 6 Townhomes

301 Nursery Hill Drive, View Royal, BC

Date: 2011.11.04 Sheet: A8

Architectural floor plans showing the layout, dimensions, and unit areas for Townhouse Building 1 (Duplex) and Townhouse Building 2 (Fourplex), including Main Level, Lower Level, and Upper Level views.
Architectural floor plans showing the layout, dimensions, and unit areas for Townhouse Building 1 (Duplex) and Townhouse Building 2 (Fourplex), including Main Level, Lower Level, and Upper Level views.

Townhouse Building 1 (Duplex) - Scale 1:100

Level Unit Area Garage Detail
Main Level Left Unit 80 m2 35.4 m main (35.3 m lower)
Right Unit 80 m2 33.8 m main (33.8 m lower)
Lower Level Left Unit 85 m2 -
Right Unit 85 m2 -

Note: Lower Level includes unexcavated areas.

Townhouse Building 2 (Fourplex) - Scale 1:100

Level Unit Area Garage Detail
Main Level Unit 1 (Far Left) 80 m2 33.2 m garage
Unit 2 80 m2 33.7 m garage
Unit 3 80 m2 33.8 m garage
Unit 4 (Far Right) 85 m2 34.0 m garage
Upper Level Unit 1 (Far Left) 81 m2 -
Unit 2 81 m2 -
Unit 3 81 m2 -
Unit 4 (Far Right) 81 m2 -

Handwritten Note: ATTACHMENT 13

Page 44
