SITE PLAN OF LOT 4, SECTION 6, LAKE DISTRICT

December 6, 2016Page 261 section

Survey site plan for 107 Meadow Park Lane showing building footprint and covenant areas.

8.1.a) Development Variance Permit No. 2016/10 - 107 Meadow Park Lane
Surveyed by Island Land Surveying Ltd.Date: January 6, 2016Refers to Covenant E577554

SITE PLAN OF LOT 4, SECTION 6, LAKE DISTRICT (LYING PARTLY IN ESQUIMALT DISTRICT), PLAN VIP72720

Detailed site plan map showing property boundaries of Lot 4, surrounding parcels (REM Section 2, Plan VIP72722, Lot 9, Lot 3, Lot 5 VIP72720), a building envelope, topographical elevation points, and Meadow Park Lane.
Detailed site plan map showing property boundaries of Lot 4, surrounding parcels (REM Section 2, Plan VIP72722, Lot 9, Lot 3, Lot 5 VIP72720), a building envelope, topographical elevation points, and Meadow Park Lane.

NOTES

  • Lot information, offsets, and areas shown may vary upon completion of a comprehensive legal survey. Elevations shown are based upon an ASSUMED datum.
  • This plan is for building design & permit purposes only and is for the exclusive use of our client. This plan must not be used to define property lines or property corners. Underground intervals have not been included or considered.

LEGEND

  • MH: Denotes sewer manhole
  • LS: Denotes lamp standard
  • HV: Denotes hydrant control valve
  • IV: Denotes irrigation control valve
  • O IP: Denotes Iron Pin (found) location, diameter & direction
  • 32.55: Denotes ground elevation

SURVEY DETAILS

  • Field survey date: December 28, 2015.
  • Parcel Charges: The parcel is subject to charges: Covenant E577554.
  • Scale: 1:150 (all distances are in metres).

FILE INFORMATION

  • File: 554-A6-P-LOT 4-BP
  • Date: January 8, 2016
  • Surveyor: Island Land Surveying Ltd.
