Council Meeting/Documents/Height Calculations & Elevations
Appendix

Height Calculations & Elevations

December 6, 2016Page 281 section

Technical drawings showing the right and rear elevations with height calculations for the addition.

8.1.a) Development Variance Permit No. 2016/10 - 107 Meadow Park Lane
Average Grade calculated at 29.12mFinished Floor Elev 29.70m

HEIGHT CALCULATIONS

Point Elevation Segment Calculation
A 29.2 A-B 29.2 X 12.92
B 28.9 B-C 29.1 X 15.36
C 28.9 C-D 29.0 X 7.01
D 29.1 D-E 29.09 X 5.79
E 29.0 E-F 28.95 X 7.01
F 28.9 F-G 28.91 X 1.067
G 28.8 G-H 28.85 X 7.56
H 28.8 H-I 28.85 X 1.921
I 28.8 I-J 28.75 X 4.877
J 28.7 J-A 28.95 X 12.802

291.135 / 10 = 29.113m

Peak Elev. = 37.94 Mid Point = 34.89 AVE. ELEV = 29.05 HEIGHT = 34.89 - 29.05 = 5.84

(377.264 + 443.904 + 203.29 + 168.12 + 202.94 + 30.84 + 218.11 + 55.42 + 140.21 + 370.62) / (12.92 + 15.36 + 7.01 + 5.79 + 7.01 + 1.067 + 7.56 + 1.921 + 4.877 + 12.802) = 2210.748 / 76.358 = 28.95

Architectural drawing showing the Right Elevation and Rear Elevation for the Ware Residence, including existing structures and a proposed addition, detailed with height calculations.
Architectural drawing showing the Right Elevation and Rear Elevation for the Ware Residence, including existing structures and a proposed addition, detailed with height calculations.

RIGHT ELEVATION

  • EXISTING RESIDENCE
  • PROPOSED ADDITION
  • LAMINATE SHINGLES
  • HARDIPLANK SIDING

REAR ELEVATION

  • LAMINATE SHINGLES
  • LINE OF CEILING

PROJECT INFORMATION

  • Firm: Parsons & Hubbard Ltd.
  • Address: 2814 Graham Road, Sechelt BC, V0N 3A1
  • Phone: 250-881-3720
  • Project Name and Address: WARE RESIDENCE
  • Sheet: ADDITION
  • Date: Mar 1/16
  • Scale: 1/4" = 1'
  • Sheet Number: 3
Page 28
