Council Meeting/Documents/Site Plan – DVP Application – Jedburgh Rd
Appendix

Site Plan – DVP Application – Jedburgh Rd

December 6, 2016Page 461 section

Proposed subdivision and road dedication site plan prepared by Active Earth Engineering Ltd.

8.1.c) Development Variance Permit No. 2016/17 - 14 and 24 Jedburgh Road
Proposed 9 lot subdivision4m road dedication as shownDate: July 2016

PROPOSED 9 LOT SUBDIVISION

14 JEDBURGH RD, VIEW ROYAL

SITE PLAN - DVP APPLICATION

Site plan illustrating the proposed 9-lot subdivision at 14 Jedburgh Road. The plan displays lots FS A through FS D and S1 through S5 with their calculated areas. It includes a key plan, north arrow, and annotations for road dedications, a siting variance for lot 24, and a proposed land transfer.
Site plan illustrating the proposed 9-lot subdivision at 14 Jedburgh Road. The plan displays lots FS A through FS D and S1 through S5 with their calculated areas. It includes a key plan, north arrow, and annotations for road dedications, a siting variance for lot 24, and a proposed land transfer.

Project Information

  • AEE PROJECT: 1133
  • ISSUED: JULY 2016
  • DRAWN BY: JKS
  • CHECKED BY: MJA

Lot Area Summary

  • FS A: 615 m²
  • FS B: 612 m²
  • FS C: 628 m²
  • FS D: 610 m²
  • S1: 629 m²
  • S2: 615 m²
  • S3: 676 m²
  • S4: 827 m²
  • S5: 705 m²

Plan Annotations and Notes

  • Development Variance Application: Requesting to eliminate all frontage improvements along the Old Island Highway (South of proposed development at 14 Jedburgh Rd).
  • Road Dedication: 4m strip indicated as "dedicated as road" along Jedburgh Road.
  • Siting Variance: 1.9 m siting variance noted on the northern portion of lot 24.
  • Land Transfer: Area designated for "Land transfer to 24 Jedburgh" located south of lot 24.
  • Existing House: "EXISTING HOUSE TO BE REMOVED" noted on Lot S5 (14 Jedburgh Road).
  • Access: Interior lots are served by "C.P. STRATA - ACCESS".
  • Surrounding Properties: Adjacent lots labeled 20 A and 24. Boundaries are marked with dimensions in meters.
Page 46
