Aerial photograph with annotated measurements of the existing building and site layout.

Measurements show building setbacks and total site width

Attachment F

Aerial view of a building and surrounding parking lot with overlaid measurement lines. Key annotations include "6.63 m" for a parking width, "Total 14.32 m" for the building width, and "Total 53.63 m" for a longer distance across the site. A large letter "B" with arrows is marked on the building's roof.
Aerial view of a building and surrounding parking lot with overlaid measurement lines. Key annotations include "6.63 m" for a parking width, "Total 14.32 m" for the building width, and "Total 53.63 m" for a longer distance across the site. A large letter "B" with arrows is marked on the building's roof.
