Committee of the Whole/Documents/Island Highway: Concepts Evaluated (Technical Drawings)
Appendix

Island Highway: Concepts Evaluated (Technical Drawings)

December 10, 2013Pages 159–1602 sections

Schematic drawings showing proposed queue jumper lanes for transit at Six Mile Road and Colwood Interchange.

1 CALL TO ORDER
Concept 2 - Six Mile NB Queue JumperConcept 3 - Colwood Interchange NB Queue Jumper

Island Highway: Concepts Evaluated

Concept 2 – Six Mile NB Queue Jumper to Intersection

Map diagram of Concept 2 design for Island Highway, showing road lane configurations between Hart Road and Six Mile Road, labeled P154
Map diagram of Concept 2 design for Island Highway, showing road lane configurations between Hart Road and Six Mile Road, labeled P154
Page 159–160

Island Highway: Concepts Evaluated

Concept 3 – Colwood Interchange/Intersection NB Queue Jumper

Map diagram of Concept 3 design showing modifications to the Colwood Interchange involving Old Island Highway, Trans Canada Highway, and Burnside Road West, labeled P155
Map diagram of Concept 3 design showing modifications to the Colwood Interchange involving Old Island Highway, Trans Canada Highway, and Burnside Road West, labeled P155
Page 159–160
Extracted from: 2013 12 10 Committee of the Whole Agenda
