DVP 2013/05 Proposed Strata Lot Plans
Engineering plans showing building envelopes and existing structures on the strata lots.
BUILDING ENVELOPES ON PROPOSED STRATA LOTS 1 TO 4, SECTION 3, ESQUIMALT DISTRICT, STRATA PLAN EPS
ATTACHMENT 4
Proposed Strata Lots 1 to 4 may be subject to charges:
- Right of Way 322733E & J11190
- Statutory Right of Way EW40004
NOTES: For subdivision purposes only. Dimensions and areas shown are based on land title office records and may vary upon completion of a comprehensive Legal Survey. This plan must be approved by approving authority prior to reliance.
File: SE-LAU-MW10-2 Date: February 16, 2014 Island Land Surveying Ltd.
EXISTING STRUCTURES ON PROPOSED STRATA LOTS 1 TO 4, SECTION 3, ESQUIMALT DISTRICT, STRATA PLAN EPS
ATTACHMENT 5
Proposed Strata Lots 1 to 4 may be subject to charges:
- Right of Way 322733E & J11190
- Statutory Right of Way EW40004
| R-1 Zone | Minimum Requirements | Proposed Strata Lot 1 | Proposed Strata Lot 2 | Proposed Strata Lot 3 | Proposed Strata Lot 4 |
|---|---|---|---|---|---|
| Front Yard | 7.5m | 8.9m | 31.2m | — | 8.5m |
| Rear Yard | 7.5m | — | 8.5m | — | 3.5m |
| Side Yard | 2.14m, providing sum of the two side yards is not less than 4.5m | — | 2.2m and 4.4m totaling 6.6m | — | 1.5m and 4.5m totaling 6.0m |
| Lot Area | 1000 sq.m. | 1000 sq.m. | 903 sq.m. | 903 sq.m. | 1276 sq.m. |
| Lot Width | 17.5m | 21.3m | 19.4m | 20.7m | 25.2m |
| Gross Floor Area | 40% of lot area, not to exceed 270 Sq.m. | — | 102.8 Sq.m. | — | 191.6 Sq.m. |
NOTES: Location of existing structures and floor areas have been provided by client. FOR SUBDIVISION PURPOSES ONLY. Dimensions and areas shown are based on land title office records and may vary upon completion of a comprehensive Legal Survey. This plan must be approved by approving authority prior to reliance.
File: SE-LAU-MW10-2 Date: July 16, 2013 Island Land Surveying Ltd.
