Committee of the Whole/Documents/Attachment 5 - Conceptual Building Illustrations
Appendix

Attachment 5 - Conceptual Building Illustrations

May 13, 2014Pages 98–1022 sections

Architectural renderings and floor plans for the proposed townhouse and duplex units at 102 Atkins Road.

2. APPROVAL OF AGENDA
Duplex unit main floor: 832 sq ftDetached unit main floor: 1,010 sq ft

102 ATKINS ROAD - DUPLEX PLAN

Architectural rendering showing a perspective view of the duplex exterior.
Architectural rendering showing a perspective view of the duplex exterior.
Architectural rendering showing a perspective view of the duplex exterior from a different angle.
Architectural rendering showing a perspective view of the duplex exterior from a different angle.

Floor Plans

Floor plans for the Lower, Main, and Upper floors of the duplex.
Floor plans for the Lower, Main, and Upper floors of the duplex.

LOWER FLOOR

  • Area: 500 square feet plus 301 square foot garage
  • Recreation Room: 19'9" x 15'7"
  • Garage: 12'7" x 22'
  • Width: 42'-1"

MAIN FLOOR

  • Area: 832 square feet
  • Family Room: 11'7" x 16'1"
  • Dining Room: 9'4" x 10'5"
  • Living Room: 12'9" x 13'7"
  • Depth: 51'-6"

UPPER FLOOR

  • Area: 819 square feet
  • Master Bedroom: 10'11" x 14'7"
  • Bedroom: 10'4" x 10'11"
  • Bedroom: 9'3" x 9'7"
Page 98–102

102 ATKINS ROAD - THE WESCOTT

Front rendering and floor plans for "The Wescott" residence.
Front rendering and floor plans for "The Wescott" residence.

MAIN FLOOR

  • Garage: 420 square feet
  • Living: 1,010 square feet
  • Dimensions: 34'-0" x 42'-4"

UPPER FLOOR

  • Area: 1,149 square feet
Architectural rendering and floor plans for "The Wescott" residence.
Architectural rendering and floor plans for "The Wescott" residence.
Page 98–102
