Presentation

PSAC - Fascia display options and site photos

May 13, 2014Pages 126–1291 section

Design options for the proposed PSAC signage and photos of the existing building storefronts.

2. APPROVAL OF AGENDA
Sign dimensions: 30" x 14'Option B: Proposed backlit fascia sign

Public Service Alliance of Canada / Alliance de la Fonction publique du Canada

Sign Proposal: Option B

Rendering of a proposed backlit fascia sign for the Public Service Alliance of Canada, positioned on a commercial building above existing "Curves" and "Drycleaners" storefronts.
Rendering of a proposed backlit fascia sign for the Public Service Alliance of Canada, positioned on a commercial building above existing "Curves" and "Drycleaners" storefronts.

Sign Dimensions: 30" x 14'
Handwritten annotations: 0.76m x 4.26m; 25.213 sq ft; 3.3818 m²

NOTE: Placement on building is approximate, a site survey will be required.

Reference Photos of Existing Site

Close-up photograph of the "Curves" and "Drycleaners" storefronts used for the sign rendering.
Close-up photograph of the "Curves" and "Drycleaners" storefronts used for the sign rendering.
Wide-angle photograph of the shopping center storefronts including "Curves", "Avalon Laundromat", and "Sears", with a "LOADING ZONE 10 MIN MAX" area in the foreground.
Wide-angle photograph of the shopping center storefronts including "Curves", "Avalon Laundromat", and "Sears", with a "LOADING ZONE 10 MIN MAX" area in the foreground.
Wide-angle photograph showing the "Dollar Store" storefront and parking area of the commercial building.
Wide-angle photograph showing the "Dollar Store" storefront and parking area of the commercial building.

Project Information

Field Details
Contact Information TRIAD SIGN
560 Alpha St. Victoria, B.C. V8Z 1B2
Phone: 1-877-388-3993
Fax: 388-3973
www.triadsign.com
File PSAC - fascia display options - 010414
Date 01/04/14
Page 2 of 2
Description Proposed backlit fascia sign - Options
Drawn By Lori Mackenzie
Sales Rep Rick Przybysz
Customer Approval Signature: ____________________

This artwork is protected by copyright. Established 1902.

Page 126–129
