Subdivision Plan VIP86689

Subdivision Plan of:

Part of Lot 1, Plan 24900; Except Part in Plan 27155;
Parcel A (DD 184242 I) of Lot 20, Plan 748;
Both of Section 98, Esquimalt District.

BCGS 92B.043 Scale 1:500

Legend

Grid Bearings are derived from observations between geodetic control monuments 88H3847 and 88H3850 (City of Colwood, ISA No. 40). This plan shows horizontal ground-level distances, except where otherwise noted. To compute grid distances, multiply ground-level distances by combined factor of 0.999612.

All distances are in metres and decimals. Bearings are shown in degrees, minutes and seconds.

Symbol	Description
●	Lead Plug Found
⊡	Standard Iron Post Found
⏺	Standard Iron Post Placed
○	Old Iron Post Found
⊛	Control Monument Found
rock	Short Iron Post set in rock
conc	denotes used in concrete
U	Unregistered Lead Plug Found

Detailed subdivision plan map showing 'A' (828.5 m²), Rem 1, Pt 1 (Plan 24900), and an "Area of road dedication" (58.4 m²) located between Wilfert Road and Section 98. Surrounding features include Section 104, Section 1, Old Island Highway (Plan 649 RW), and Plan 37130 (DND Lands).

Owners

0713915 B.C. Ltd. (Inc. No. BC0713915)
Helena de Amaral
- Occupation: Receptionist
- Address: 2027 Gillespie Rd., Sooke, BC
Robert Ruskin Fisher
- Occupation: Receptionist
- Address: 2027 Gillespie Rd., Sooke, BC

Mortgagees

Bentall Balanced Mortgage Fund Ltd.
- Authorized Signatories: D. Danton, M. Davidson

Approvals

Town of View Royal: Approved under the Land Title Act this 1st day of December, 2008. Re-approved this 30th day of March, 2009.
British Columbia Hydro and Power Authority: Approved as to dedication of road by its charge 122733G (Ref. 122733G).
- Address: 333 Dunsmuir St., Vancouver, BC V6B 5R3
Town of View Royal (Covenant): Approved as to Covenant.

Surveyor's Certificate

I, Wade C. Riley, a British Columbia Land Surveyor, of the city of Victoria, in British Columbia, certify that I was present at and personally superintended the survey represented by this plan, and that the survey and plan are correct. The field survey was completed on the 28th day of August, 2008. The plan was completed and checked, and the checklist filed under #55342, on the 9th day of September 2008.

Michael J. McElhanney Land Surveying Inc. #113 - 2244 Sooke Road Victoria, B.C. V9B 1X1 (250) 474-5538 File: 3528238-A-sub
