Site Plan - Lot A, Section 98, Esquimalt District

February 11, 2014Page 1001 section

Detailed site layout showing building footprint and driveway for 280 Wilfert Road.

2. APPROVAL OF AGENDA
Dated Nov 28, 2013

Site Plan Of: Lot A, Section 98, Esquimalt District, Plan VIP86689.

Scale = 1:200

Dated this 28th day of November, 2013.

Elevations are based upon geodetic datum. Elevations & distances shown are in metres.

Site plan for Lot A, Section 98 on Wilfert Road, showing property boundaries, dimensions, and existing features including a concrete sidewalk, interlocking paver driveway, deck, planter, and utility locations (gas service, utility pole, water meter). Adjacent properties identified include Rem 1 Plan 24900 to the north and 15 Plan 37130 to the south.
Site plan for Lot A, Section 98 on Wilfert Road, showing property boundaries, dimensions, and existing features including a concrete sidewalk, interlocking paver driveway, deck, planter, and utility locations (gas service, utility pole, water meter). Adjacent properties identified include Rem 1 Plan 24900 to the north and 15 Plan 37130 to the south.

The subject property is affected by the following registered documents: 122733G, CA848867, FB269924.

RICHARD J. WEY & ASSOCIATES Land Surveying Inc. www.waysurveys.com #4-2227 James White Boulevard Sidney, BC V8L 1Z5 Telephone (250) 656-5155 File: 130331\SIT\LE

Page 100
