SUBDIVISION PLAN OF PART OF LOT 29, SECTION 98 (2427 Chilco Rd)

December 9, 2014Page 672 sections

Survey plan showing the proposed Lot 1 and the remainder lot for the 2427 Chilco Road subdivision.

2. APPROVAL OF AGENDA
Proposed Lot 1 size: 0.795 Ha

Report to Committee of the Whole

Page 67

Development Variance Permit 2014/04 – 2427 Chilco Rd

Meeting Date: December 9, 2014

Attachment 3. Proposed Lot 1 Site Plan

SUBDIVISION PLAN OF PART OF LOT 29, SECTION 98, ESQUIMALT DISTRICT, PLAN 748, EXCEPT PART IN PLAN VIP67813.

PLAN EPP45786.

BCGS 92B.043

Detailed subdivision site plan for 2427 Chilco Road showing proposed Lot 1, Remainder 29, and adjacent Lot 28, including Chilco Road frontage and technical survey bearings and distances.
Detailed subdivision site plan for 2427 Chilco Road showing proposed Lot 1, Remainder 29, and adjacent Lot 28, including Chilco Road frontage and technical survey bearings and distances.

Survey Notes and Legend

  • Scale: 1:500. All distances are in metres.
  • The intended plot size of this plan is 432 mm in width by 560 mm in height (C Size) when plotted at a scale of 1:500.
  • Grid bearings are derived from GNSS observations and are referred to the central meridian of UTM Zone 10. To obtain local astronomic bearings referred to the meridian passing through Iron Post 1, subtract 0° 21’ 13”.
  • The UTM coordinates and estimated horizontal positional accuracy achieved are derived from single point positioning techniques using the Precise Point Positioning (PPP) services of Natural Resources Canada.
  • This plan shows horizontal ground-level distances, unless otherwise specified. To compute grid distances, multiply ground-level distances by the average combined factor of 0.9996105. The average combined factor has been determined based on an ellipsoidal elevation of 35 metres.
  • LEGEND
    • ● Found
    • ○ Placed
    • IP Denotes Standard Iron Post

Technical Data

Point 1 Point 2
Datum NAD83 (CSRS) 3.0.0.BC.1.CRD UTM Zone 10 NAD83 (CSRS) 3.0.0.BC.1.CRD UTM Zone 10
UTM Northing 5367294.10 5367302.29
UTM Easting 465039.56 465077.68
Point Combined Factor 0.9996107 0.9996109
Est. Horiz. Positional Accuracy 0.05m 0.05m

Plan Information

  • Proposed Lot 1 Area: 0.793 Ha.
  • Chilco Road: Gazetted as Road March 13, 1924.
  • File: 0978-JK-97
  • Archive: 97-Limoana-P7-MN8
  • Survey Firm: Island Land Surveying Ltd., 1-15 Cadillac Avenue, Victoria B.C. V8Z 1T3 (TEL 250.475.1515)
  • This plan lies within the jurisdiction of the Approving Officer for the Town of View Royal.
  • This plan lies within the Capital Regional District.
  • The field survey represented by this plan was completed on the 17th day of October, 2014.
  • Jason C. Kozina, BCLS 767
