Bicycle Wayfinding Sign Templates

March 10, 2015Pages 348–3536 sections

Visual design specifications for various bicycle route wayfinding signs (Decision, Turn, Confirmation, etc.).

2 APPROVAL OF AGENDA
Decision Sign size: 24 x 30 inchesConfirmation Sign size: 24 x 24 inches

DECISION SIGN

24 x 30 INCHES

Green rectangular bicycle directional sign with three destination panels and arrows.
Green rectangular bicycle directional sign with three destination panels and arrows.
  • Bicycle symbol
  • ↑ Destination I
  • ← Destination II via xxxxx
  • Destination III →
Page 348–353

TURN FINGERBOARD RIGHT

9 x 34 INCHES

Green right-pointing fingerboard sign featuring a bicycle icon and text for two destinations.
Green right-pointing fingerboard sign featuring a bicycle icon and text for two destinations.
  • Bicycle symbol
  • Destination I
  • Destination II
Page 348–353

TURN FINGERBOARD LEFT

9 x 34 INCHES

Green left-pointing fingerboard sign featuring a bicycle icon and text for two destinations.
Green left-pointing fingerboard sign featuring a bicycle icon and text for two destinations.
  • Bicycle symbol
  • Destination I
  • Destination II
Page 348–353

CONFIRMATION SIGN

24 x 24 INCHES

Green rectangular bicycle confirmation sign listing destinations and placeholder distance values.
Green rectangular bicycle confirmation sign listing destinations and placeholder distance values.
  • Bicycle symbol
  • Destination I XX
  • Destination II via xxxxx XX
  • Destination III XX
Page 348–353

OFF-NETWORK WAYMARKER

12 x 18 INCHES

Green waymarker sign with an upward-pointing white chevron, bicycle symbol, and "To ROUTE" text.
Green waymarker sign with an upward-pointing white chevron, bicycle symbol, and "To ROUTE" text.

To Bicycle symbol ROUTE

Page 348–353

MAP DECISION SIGN

24 x 30 INCHES

Green rectangular map decision sign with a bicycle symbol, the text "BIKE ROUTE", and a white path diagram showing a three-way split.
Green rectangular map decision sign with a bicycle symbol, the text "BIKE ROUTE", and a white path diagram showing a three-way split.

BIKE ROUTE

Page 348–353
