Committee of the Whole/Documents/Thetis Glen Exterior Colours Concept
Appendix

Thetis Glen Exterior Colours Concept

May 12, 2015Pages 95–982 sections

Visual rendering and palette description of proposed exterior materials and color schemes.

9.2.3 a Mixed Residential Form and Character Development Permit No. 2014/10 - 2429 Chilco Road Lot 20 (Thetis Vale Phase 6 - 16 Duplex Residential Units)
Color schemes including 'Caramel Apple', 'Gloucester Sage', and 'Florentine Plaster'Accent colors: 'Crown Point Sand' and 'Fairview Taupe'

THETIS GLEN - EXTERIOR COLOURS

Architectural rendering of houses labeled Block 4-20 through Block 8-20, featuring exterior paint color swatches for body and accent colors.
Architectural rendering of houses labeled Block 4-20 through Block 8-20, featuring exterior paint color swatches for body and accent colors.

Exterior Colour Specifications by Block

Block Body Color Accent Color
Block 4-20 Fairview Taupe (HC-85) Crown Point Sand (HC-90)
Block 5-20 Caramel Apple (CC-450) Bluffs (CC-338)
Block 6-20 Florentine Plaster (CC-520) Gloucester Sage (HC-100)
Block 7-20 Caramel Apple (CC-450) Bluffs (CC-338)
Block 8-20 Fairview Taupe (HC-85) Crown Point Sand (HC-90)

Standard Colours

  • Trim: White Dove (OC-17)
  • Accents: Black (2132-10)
Page 95–98

SITE PLAN - LOT 20

Development site plan for Lot 20 indicating the distribution of paint schemes across lots 1-20 through 8-20, with corresponding color swatches and annotations.
Development site plan for Lot 20 indicating the distribution of paint schemes across lots 1-20 through 8-20, with corresponding color swatches and annotations.

Paint Schemes by Lot

Scheme Applied to Lots Body Color Accent Color
Scheme 1 1-20, 3-20 Inukshuk (CC-460) Buckhorn (CC-510)
Scheme 1K 2-20 Kendall Charcoal (HC-166) Florentine Plaster (CC-520)
Scheme 2 4-20, 8-20 Fairview Taupe (HC-85) Crown Point Sand (HC-90)
Scheme 2K 5-20, 7-20 Caramel Apple (CC-450) Bluffs (CC-338)
Scheme 2B 6-20 Florentine Plaster (CC-520) Gloucester Sage (HC-100)

Additional Trim and Accent Details

  • Trim Colour: White Dove (OC-17)
  • Accent: Black (2132-10)

Site plan Context

  • Adjacent Landmarks: Trans Canada Highway, Park, REM. 30 PLAN 748
  • Note: JAVA (indicated near architectural roof detail)
Page 95–98
