Driveway & Parking Illustration

May 12, 2015Pages 110–1111 section

Simplified diagram showing vehicle access routes and parking stall locations for the East Townhomes.

9.2.3 a Mixed Residential Form and Character Development Permit No. 2014/10 - 2429 Chilco Road Lot 20 (Thetis Vale Phase 6 - 16 Duplex Residential Units)
Scale 1:200

THETIS VALE TOWNHOME DRIVEWAY & PARKING ILLUSTRATION

1:200

Site plan illustration for North Townhomes, marked with a large red X
Site plan illustration for North Townhomes, marked with a large red X

NORTH TOWNHOMES

EAST TOWNHOMES

  • GREEN SPACE 0.11 ha.
  • GREEN SPACE 0.06 ha.
  • GREEN SPACE 0.07 ha.
