Committee of the Whole/Documents/Subject Property Map and Site Plan - Lot 21
Appendix

Subject Property Map and Site Plan - Lot 21

May 12, 2015Pages 135–1372 sections

Location map and general site plan for the 6-unit North Townhomes development area.

9.2.3 b Mixed Residential Form and Character Development Permit No. 2014/12 - 2429 Chilco Road Lot 21 (Thetis Vale Phase 6 - 6 Duplex Residential Units)
Site area = 3952 m²

Subject Property Map - 2429 Chilco Rd Lot 2130

A property map highlighting the "Subject Property" at 2429 Chilco Road, Lot 2130. The map shows the property's orientation relative to Cheam Road, Chilco Road, Cahlity Lane, and the Trans Canada highway. Surrounding lot numbers and addresses are indicated.
A property map highlighting the "Subject Property" at 2429 Chilco Road, Lot 2130. The map shows the property's orientation relative to Cheam Road, Chilco Road, Cahlity Lane, and the Trans Canada highway. Surrounding lot numbers and addresses are indicated.
Page 135–137

Thetis Vale Phase 6 - Site Plan

A preliminary draft site plan for Limona Construction's Thetis Vale Phase 6 project. The plan depicts residential lot layouts (Lots 1-19), designated townhouse areas ("Townhouse North" and "Townhouse East"), green spaces, and the extension of Cheam Road and Chilco Road near the Six Mile exit ramp.
A preliminary draft site plan for Limona Construction's Thetis Vale Phase 6 project. The plan depicts residential lot layouts (Lots 1-19), designated townhouse areas ("Townhouse North" and "Townhouse East"), green spaces, and the extension of Cheam Road and Chilco Road near the Six Mile exit ramp.

Project Information

Project No. Scale Project Subject Drawing Number Rev. No.
20132450 1:500 THETIS VALE PHASE 6 SITE PLAN 2450-00-C.101 C

Revision History

No. Date Eng. By Subject
0 AUG 1, 2014 SD DAH RE-ISSUED FOR APPROVAL
B JUN 13, 2014 SD DAH ISSUED FOR APPROVAL
A MAR 3, 2014 SD DAH ISSUED FOR REVIEW

Site Plan Notes and Annotations

  • SITE: Indicated by a red arrow near the northern townhouse cluster.
  • Residential Areas:
    • TOWNHOUSE NORTH
    • TOWNHOUSE EAST
    • Lots 1 through 19
  • Green Spaces:
    • GREEN SPACE (0.11 ha)
    • GREEN SPACE (0.07 ha)
    • GREEN SPACE (0.13 ha)
  • Roadways:
    • CHEAM ROAD
    • CHILCO ROAD
    • SIX MILE EXIT RAMP
  • Technical and Construction Notes:
    • MORTARED BOULDER STACKED WALL C/W FENCING DESIGNED AS PER LEVELTON DETAILS SHEET C.109 (TYP.)
    • 1.5m BENCH REQD AS PER LEVELTON DETAIL SHEET C.109
    • SURVEY MONUMENT REQUIRED - LOCATION TO BE DETERMINED BY TOVR
    • COVENANT FOR CERTAIN DRAINS TO BE TIED INTO HOUSE SYSTEMS (TYP.)
    • TOWN OF VIEW ROYAL TO DETERMINE USE FOR EXISTING CONCRETE BARRIERS (TYP.) - ENSURE SUFFICIENT SUBBASE IN AREAS WHERE THERE IS SLOUGHING
    • SAW CUT WITH BUTT JOINT C/W JOINT SEAL AS REQ'D

THIS PAGE INTENTIONALLY LEFT BLANK

Page 135–137
