Committee of the Whole/Documents/Lot 21 Technical Illustrations
Appendix

Lot 21 Technical Illustrations

May 12, 2015Pages 154–1612 sections

Renderings, line of sight profiles, parking layouts, and erosion control plans for the North Townhomes.

9.2.3 b Mixed Residential Form and Character Development Permit No. 2014/12 - 2429 Chilco Road Lot 21 (Thetis Vale Phase 6 - 6 Duplex Residential Units)
Retaining walls shown on north side up to 4.4m
Rendering of a row of townhouses with trees in autumn foliage colors
Rendering of a row of townhouses with trees in autumn foliage colors
Rendering of a residential streetscape featuring townhouses, landscaped lawns, and people walking on a paved path
Rendering of a residential streetscape featuring townhouses, landscaped lawns, and people walking on a paved path
Photograph showing a green two-story building adjacent to a wet roadway with a concrete barrier and forested background
Photograph showing a green two-story building adjacent to a wet roadway with a concrete barrier and forested background
Page 154–161

Limona Construction - Thetis Vale Phase 6

Six Mile Exit Line of Sight

Engineering plan showing profiles of sections A-A and B-B, and a site map detailing the Six Mile Exit line of sight and proximity to a highway offramp
Engineering plan showing profiles of sections A-A and B-B, and a site map detailing the Six Mile Exit line of sight and proximity to a highway offramp
  • Section A-A 1:250 Profile
  • Section B-B 1:250 Profile

Typical Cross Sections

Engineering drawing displaying multiple cross sections (1-1 through 5-5) and a site plan layout for the townhouse development
Engineering drawing displaying multiple cross sections (1-1 through 5-5) and a site plan layout for the townhouse development

Volume Calculations

Description Quantity
CUT 28,800 m³
FILL 33,500 m³
(Excludes stripping and bulking)

Cross Sections Included:

  • X-Section 1-1
  • X-Section 2-2
  • X-Section 3-3
  • X-Section 4-4 (Mortared rock wall Chilco frontage typ.)
  • X-Section 5-5

Thetis Vale Townhome Driveway & Parking Illustration

Detailed site illustration for the North Townhomes and East Townhomes sections, showing driveway and parking configurations
Detailed site illustration for the North Townhomes and East Townhomes sections, showing driveway and parking configurations

Grading & Erosion Control Plan

Technical site plan detailing grading specifications, boulder wall limits, silt fence locations, and construction details
Technical site plan detailing grading specifications, boulder wall limits, silt fence locations, and construction details

Legend

  • TYPE C, TYPE A, TYPE B: Building unit types
  • BOULDER WALL LIMITS: Indicated by dashed line with circles
  • SILT FENCE: Indicated by dashed line with "x" marks
  • 40.8: Underside of footing elevation (cut)
  • 40.8: Underside of footing elevation (fill)
  • Ex. 38.38 / (43.350): Proposed grade & road centerline
  • 45.3: Lot pad excavation elevation

Sediment & Erosion Control Notes

  1. Silt fence to be installed as required on construction site boundaries to contain sediment laden runoff onsite. Siltation control measures to be monitored and cleaned regularly.
  2. Existing manholes & catchbasins on Chilco Road to be protected with filter cloth & cleaned regularly throughout construction.
  3. Silt fence to be installed around base of material stockpiles. Stockpiles to be covered as required during precipitation to reduce erosion and washing out of fines.
  4. Silt fence to be installed as directed by Engineer on steep slopes to reduce overland runoff flow velocities and resultant sedimentation and erosion.
  5. Sweeping program to be in place to ensure soil does not accumulate on Chilco Road.
  6. Hay bale silt fencing to be installed in downstream ditches to ensure removal of sediment from runoff.
  7. Existing vegetation to be maintained until removal is necessary to commence construction activities.
  8. Vegetated buffer strip to be maintained where possible around construction site perimeter until removal is required for construction or landscaping.
  9. All sediment and erosion control measures are to be removed by contractor only after vegetation is established and erosion/sedimentation does not occur.

Technical Details

  • Detail 1: Catch Basin Siltation Control - Shows sediment trap, filtered water path, and catchbasin structure.
  • Detail 2: Hay Bale Silt Fence - Shows wedge loose straw between bales, straw bale, compact soil, and flow direction.
  • Detail 3: Silt Fence - Shows steel T-bar post (1.5m long), wrap iron of bales with Alex 4551 filter fabric or approved equal, and existing ground level.
Page 154–161
