Site Plan - 102 Atkins Road Development Permit

February 10, 2015Page 451 section

Detailed site plan layout showing building locations, hard surfaces, and green space for 102 Atkins Road.

9.2.3.a Official Community Plan Amendment No. 2014/02 and Rezoning Application No. 2014/13 - 102 Atkins Road
Total Site Area: 6647 m2Green Space: 3766 m2 (57%)9 detached units shown

102 atkins road DEVELOPMENT PERMIT

development permit 102 ATKINS ROAD VIEW ROYAL B.C.

EN VIRO TEC GENERAL CONTRACTING LTD.

Site Plan map for 102 Atkins Road development showing building layouts, hard surfaces, and green spaces. The site is bounded by the Galloping Goose trail and Chilco road. Key map labels include Parcel A DD L2503, Plan 748, and Plan 1205 OS.
Site Plan map for 102 Atkins Road development showing building layouts, hard surfaces, and green spaces. The site is bounded by the Galloping Goose trail and Chilco road. Key map labels include Parcel A DD L2503, Plan 748, and Plan 1205 OS.

Site Plan Data

Category Area Percentage
Buildings 983 m² 15%
Hard Surfaces 1898 m² 28%
Green Space 3766 m² 57%
Total Site Area 6647 m² 100%

Drawing Information

  • Drawing #: 7548
  • Scale: 1:250
  • Drawn by: JDF
  • Date: 11/9/14
