Conceptual Building Illustrations - 102 Atkins Road

February 10, 2015Page 461 section

Architectural drawings showing the streetscape and various dwelling types proposed for the 102 Atkins Road development.

9.2.3.a Official Community Plan Amendment No. 2014/02 and Rezoning Application No. 2014/13 - 102 Atkins Road
Victoria Design GroupBuilding types A through E illustrated

102 ATKINS ROAD DEVELOPMENT PERMIT

Client: EN VIRO TEC GENERAL CONTRACTING LTD. Location: 102 ATKINS ROAD, VIEW ROYAL B.C.

Architectural Elevations

Front elevation rendering of House Type A
Front elevation rendering of House Type A

Street Scape

Type E Elevations and Additional Views

Drawing Details

  • Drawing #: 7548
  • Scale: 3/16" = 1'0"
  • Drawn by: JDF
  • Date: 28/10/14
