TREE PROTECTION FENCING Detail Drawing

February 10, 2015Page 991 section

Technical specification drawing for construction of tree protection fencing.

9.2.3.b Development Variance Permit No. 2015/02 - 17A Jedburgh Road
Drawing E105Oct 30/07

TREE PROTECTION FENCING

Technical drawing for tree protection fencing detail. The diagram shows a 1.20m high fence with a 2.4m maximum span between 38 x 89mm posts. It features a 38 x 89mm top rail and a 38 x 89mm bottom rail, with orange snow-fencing mesh secured to the frame with ties or staples. Posts are embedded 600mm into the ground.
Technical drawing for tree protection fencing detail. The diagram shows a 1.20m high fence with a 2.4m maximum span between 38 x 89mm posts. It features a 38 x 89mm top rail and a 38 x 89mm bottom rail, with orange snow-fencing mesh secured to the frame with ties or staples. Posts are embedded 600mm into the ground.

TREE PROTECTION FENCING

FENCE WILL BE CONTRUCTED USING 38 X 89 mm (2"X4") WOOD FRAME: TOP, BOTTOM AND POSTS. *

USE ORANGE SNOW-FENCING MESH AND SECURE TO THE WOOD FRAME WITH "ZIP" TIES OR GALVANZIED STAPLES

  • IN ROCKY AREAS, METAL POSTS (T-BAR OR REBAR) DRILLED INTO ROCK WILL BE ACCEPTED
DETAIL NAME: TREE PROTECTION FENCING
DATE: Oct 30/07
DRAWN: DM
APP'D: RR
SCALE: N.T.S.
DRAWING: E105
