Committee of the Whole/Documents/Site Plan for Subdivision Discussion - 25 Stillwater Road
Appendix

Site Plan for Subdivision Discussion - 25 Stillwater Road

February 10, 2015Page 1081 section

Preliminary land survey plan showing the proposed two-lot subdivision for 25 Stillwater Road.

9.2.3.c Environmental Development Permit No. 2014/14 - 25 Stillwater Road
Bradley V Cunnin, BCLSOctober 2014Proposed Lot A (620 m2) and Lot B (602 m2)

B.C. LAND SURVEYOR’S SITE PLAN OF:

LOT 15, SECTION 91, ESQUIMALT DISTRICT, PLAN 12112 FOR SUBDIVISION DISCUSSION PURPOSES

SCALE = 1 : 150 All distances are in metres.
MUNICIPALITY Town of View Royal
PID No. 004-954-900
ZONING R1-B
SITE AREA 1227 m²
Site plan showing proposed subdivision of Lot 15 into Prop. Lot A (620 m²) and Prop. Lot B (602 m²). The plan details existing structures at No. 25, proposed staging areas, setbacks, and proximity to Lowland Road, Stillwater Road, and Portage Inlet.
Site plan showing proposed subdivision of Lot 15 into Prop. Lot A (620 m²) and Prop. Lot B (602 m²). The plan details existing structures at No. 25, proposed staging areas, setbacks, and proximity to Lowland Road, Stillwater Road, and Portage Inlet.

LEGEND

  • Elevations are geodetic.
  • Contours are descriptive, and only accurate to +/- 1/2 interval.
  • Grade shots are taken at the point marked x.
  • grade shots at a curb line are in gutter.
  • Tree bases and canopies approximate to scale.
  • Where tree location is critical, tree species and canopy should be confirmed by qualified arborist.
Symbol Description
P denotes Utility Pole
HS denotes Manhole (Sanitary)
HS denotes Manhole (Storm)
W denotes Water Meter
g denotes guy wire

TREE SCHEDULE:

TREE No Species Diameter (m) Canopy radius (m)
TRF219 Cedar 0.54 4.5
TRF221 Cedar 0.60 7.0
TRA222 Cedar 0.47 8.0
TRF223 Fir 0.55 5.0
TRA225 Arbutus 0.72 7.0
TRD227 Fruit 2x0.30 4.0
TRB228 Birch 0.25 3.50
TRB229 Birch 0.35 5.0
TRD230 Oak 0.35 5.0
TRB231 Fruit 0.18 3.0
TRD307 Decid. 0.15 2.5
TRD309 Oak 0.45 10.0
TRD310 Oak 0.45 10.0
TRB311 Fruit 0.20 3.0
TRF312 Fir 0.40 5.0
TRD313 Decid. 0.35 4.0

PRELIMINARY

This plan is preliminary and is prepared for discussion purposes only. Lot layout and other parameters subject to Municipal interpretation.

NOTES

  • All rights reserved. No person may copy, reproduce, transmit or alter this document in whole or in part without the written consent of BCLS Inc.
  • This document was prepared for the exclusive use of our client, Josh Powar.
  • This document is intended for use as a topographic plan. It is based on Land Title Office records, and does not represent a boundary survey.
  • BCLS INC., accepts no responsibility or liability for any damages that may be suffered by a third party as a result of any decisions made or actions taken based on this document.

FILE: 11065 - 31 DRAWN: VR/my/RT 2014-10-31

Brad Cunnin Land Surveying #103 - 481 Swift Street Victoria, BC V8W 1S2 ph. 250-853-5251 fx. 381-2291 brad@bcsurveyor.ca

CERTIFIED CORRECT on the 31st day of October, 2014. Bradley V Cunnin, BCLS

Page 108
