Committee of the Whole/Documents/Site Plan at 327 Bessborough Close (J.E. Anderson)
Appendix

Site Plan at 327 Bessborough Close (J.E. Anderson)

September 8, 2015Page 521 section

Technical site plan showing lot boundaries and the proposed wall location.

9.2.3 a) Environmental Development Permit Application No. 2015/14 - 327 Bessborough Close
June 16, 2015

PLAN 1696

NOTE: ELEVATIONS ARE TO ASSUMED DATUM. THE DECIMAL POINT OF THE ELEVATION DENOTES THE LOCATION OF THE SHOT TAKEN UNLESS OTHERWISE NOTED. PROPERTY LINES HAVE BEEN CALCULATED FROM CURRENT SURVEY AND EXISTING SURVEY RECORDS.

Site plan for Strata Lot 6 at 327 Bessborough Close, showing the location of a residence, decks, rock walls, and the natural boundary at Esquimalt Harbour.
Site plan for Strata Lot 6 at 327 Bessborough Close, showing the location of a residence, decks, rock walls, and the natural boundary at Esquimalt Harbour.

SITE PLAN

AT 327 BESSBOROUGH CLOSE

Field Detail
LEGAL STRATA LOT 6, SECTION 8, ESQUIMALT DISTRICT, STRATA PLAN 1696
DRAWN BY GBL
PROJECT SURVEYOR D.R. GARNER
SCALE 1:100
DATE JUNE 16, 2015
CLIENT MR. LLOYD HAMEL
OUR FILE 29093

Plan Annotations and Labels:

  • STRATA LOT 6
  • Residence
  • Deck
  • approximate 15m setback
  • TOP CONCRETE FOOTING
  • ROCK WALL
  • TOE OF BLOCK WALL
  • CORNER OF FORM
  • NATURAL BOUNDARY AS PER STRATA PLAN 1696
  • ESQUIMALT HARBOUR
  • s/w & stairs
  • Not found
  • (IRON PIN TO CORNER) - 23.28
  • (LEAD PLUG TO CORNER) - 45.05
  • Iron Pin in Rock found (Point 165, Elevation 486.55)
  • Lead Plug found (Point 164, Elevation 486.37)
  • Temp. Nail (Point 166, Elevation 493.20)
Page 52
Extracted from: 2015 09 08 Committee of the Whole Agenda
