Committee of the Whole/Documents/Location Plan - 327 Bessborough Close
Appendix

Location Plan - 327 Bessborough Close

September 8, 2015Page 542 sections

Annotated aerial view showing the property within the local street context.

9.2.3 a) Environmental Development Permit Application No. 2015/14 - 327 Bessborough Close

Matthew Bergink

AutoCad Technician

cell 250 514 6140 email: mbergink@gmail.com

No. Date Description
1 01-02-18 Issued for D.P.
Location Plan aerial map showing property 327 Bessborough Close and surrounding lots on Bessborough Close, Bessborough Ave, and Point Rd, bordering Esquimalt Harbour.
Location Plan aerial map showing property 327 Bessborough Close and surrounding lots on Bessborough Close, Bessborough Ave, and Point Rd, bordering Esquimalt Harbour.
Page 54

Hamel Residence

Project 327 Bessborough Close Town of View Royal, BC

Drawing Title Schedule 1 Location Plan

Design / Drawn by: MDB Scale: 1:500 Drawing Number: A1.0

Page 54
Extracted from: 2015 09 08 Committee of the Whole Agenda
