Appendix: Site Plan Survey - 148 Atkins Road

June 9, 2015Page 1091 section

Detailed legal survey of the property showing tree locations and existing structures.

2. APPROVAL OF AGENDA
Firm: Island Land Surveying Ltd.Date: February 18, 2015PID: 000-104-990

SITE PLAN OF LOT 1, SECTION 98, ESQUIMALT DISTRICT, PLAN 32373

PID: 000-104-990

SCALE: 1:250. All distances are in metres.

NOTE

Dimensions shown are based upon field survey measurements and may vary from those registered. A comprehensive legal survey may reveal offsets to boundaries that differ from those shown.

Geodetic elevations are derived from geodetic control monument 84H1523 (Elev.=54.91m) and 99H2286 (Elev.=11.66m).

Civic: 148 Atkins Road

LEGEND

  • wm Denotes water meter
  • v Denotes water valve
  • (Symbol) Denotes utility pole
  • (Symbol) Denotes fire hydrant
  • .12.3 Denotes elevation
  • (Symbol) Denotes manhole
  • 101 0.50 Fir Denotes tree location, tag number, diameter and type
Topographic site plan map showing Lot 1, Section 98, Esquimalt District, Plan 32373, with an area of 1391 m². The plan details property boundaries, elevations, a retaining wall, a shed, and numerous trees with identifying tag numbers. Adjacent properties include Part Lot 6 (Plan 748) and Lot 2 (Plan 32373). The site is bordered by Atkins Road and the Canadian National Railway (Plan 1205 O.S.).
Topographic site plan map showing Lot 1, Section 98, Esquimalt District, Plan 32373, with an area of 1391 m². The plan details property boundaries, elevations, a retaining wall, a shed, and numerous trees with identifying tag numbers. Adjacent properties include Part Lot 6 (Plan 748) and Lot 2 (Plan 32373). The site is bordered by Atkins Road and the Canadian National Railway (Plan 1205 O.S.).

File Information

  • File: 97-CROSS-SP1
  • Date: February 18, 2015
  • Surveying Firm: Island Land Surveying Ltd.
  • Address: 1-15 Cadillac Avenue, Victoria B.C. V8Z 1T3
  • Contact: TEL 250.475.1515, FAX 250.475.1518, www.islandsurveying.ca

Dated this 18th day of February, 2015. Peter I. M. Broeren, BCLS © 2015 Island Land Surveying Ltd.
