Site Plan - 2329 Evelyn Heights

April 10, 2012Pages 77–782 sections

Surveyor's site plan showing existing dwelling and proposed deck extension.

2. APPROVAL OF AGENDA
Michael Claxton, B.C.L.S.January 2, 2012 survey date

Site Information

  • SITE AREA: 7226.05 SF (671.30 m²)
  • ZONING: 121-A
  • ALLOWABLE L/C (30%): 2167.81 SF (201.39 m²)
  • EXISTING L/C (23%): 1665.25 SF (154.70 m²)
  • PROPOSED L/C (2.53%): 183.25 SF (17.02 m²)
  • FLOOR AREA TO REMAIN UNCHANGED.
Page 77–78

B.C. Land Surveyor's Site Plan

Lot 34, Section 28, Plan VIP53598, Esquimalt District (Lying partly in Lake District).

  • Scale: 1:250
  • Civic Address: 2329 Evelyn Heights, Victoria, B.C.
  • P.I.D.: 017-432-036

Legend

  • 10.00: Denotes spot elevation.
  • 11.00 floor: Denotes floor elevation.
  • o/h: Denotes overhang.
Site plan of Lot 34, Section 28, showing property boundaries, existing dwelling, driveway, and a proposed deck extension with various property line dimensions and spot elevations.
Site plan of Lot 34, Section 28, showing property boundaries, existing dwelling, driveway, and a proposed deck extension with various property line dimensions and spot elevations.

Notes

  • All distances are in metres.
  • Lot dimensions derived from registered plans and not verified by this survey.
  • Offsets shown to exterior face of building.
  • This plan is prepared from unchecked field data. Check measurements prior to construction.
  • This document is for approval/discussion purposes only and not to be used for the re-establishment of property boundaries.
  • This plan was prepared for design purposes and is for the exclusive use of our client.
  • The signatory accepts no responsibility for any damages that may be suffered by a third party as a result of reproduction, transmission, or alteration to this document without consent of the signatory.

Surveyor Information

  • Michael Claxton Land Surveying Inc.
  • B.C. & Canada Lands Surveyor
  • Unit 604 4233 Commerce Circle, Victoria, B.C. V8Z 6N6
  • Phone: 250-479-2258
  • Fax: 250-479-3631
  • Email: survey@telus.ca
  • File: 18612planDWG JC B419
  • Field Survey: 01/03/12

Project Administration

  • Client: MR. CHRIS BARKER
  • Design Consultant: MESA DESIGN GROUP INC
  • Address: #202 - 4459 VIEW MONT AVE, VICTORIA, BC
  • Phone: 250-382-2333
  • Designed by: DL
  • Drawn by: DL
  • Scale: AS SHOWN
  • Drawing No: 9774-1
