Plan of Proposed Subdivision - McNeill Designs

April 10, 2012Pages 97–981 section

Proposed site plan for the two-lot subdivision at 17 Eaton Avenue.

2. APPROVAL OF AGENDA
May 16, 2011Ruhi Manshadi (Owner)Lot A and Lot B proposed

Proposed Subdivision for: Ms. Ruhi MANSHADI

Address: #17 Eaton Ave, View Royal, BC

Aerial photograph of the project site and surrounding neighborhood
Aerial photograph of the project site and surrounding neighborhood
Vicinity map showing street layout around Eaton Avenue
Vicinity map showing street layout around Eaton Avenue

Architectural Plans

Site Plan

Project Data

Project Data for Proposed Lot B Project Data for Proposed Lot A
Present Zoning: R1-A Present Zoning: R1-A
Proposed Zoning: CD ? Proposed Zoning: CD ?
Site Area: 5712 sf (530.6 sm) Site Area: 5712 sf (530.6 sm)
Proposed Site Coverage: 2030 sf = 35.5 % Proposed Site Coverage: 827 + 210 + 410 sf = 1447 sf = 25.3 %
Floor Areas: Existing Floor Area: 827 sf
Proposed FAR 0.45 = 238.77 sm = 2570 sf Proposed FAR 0.45 = 238.77 sm = 2570 sf
Upper: 1650 sf
Ground: 920 sf
TOTAL: 2570 sf
Garage: 484 sf
Gar. Excl.: (484 sf)
GFA Total: 2570 sf = 0.45 FAR
BUILDING HEIGHT: max permitted 7.5 m (24.6') BUILDING HEIGHT: max permitted 7.5 m (24.6')
Height Proposed: 7.5 m (24.6') Height Proposed: 7.5 m (24.6')

Revision History

  • REV 01: 18 MAY 2011 - New floor plans to meet 0.45 FAR
  • REV 02: 25 MAY 2011 - Adjust lot area; Property Line to equate lot areas, both 530.6 sm
  • REV 03: 04 APR 2011 - Amend Design for client. Amend FAR GFA & Site Cov. addtl photos.
