Proposed Subdivision of Lots 1 & 2 - Michael Claxton

April 10, 2012Page 1071 section

Survey plan illustrating the proposed bare land strata lots A through E.

2. APPROVAL OF AGENDA
November 5, 2009Plan 5985

B.C. Land Surveyor's Site Plan of Proposed Subdivision of Lots 1 & 2, Plan 5985, & Part of Section 92, in Plan 470R, All in Section 92, Esquimalt District.

CIVIC ADDRESS: 347 & 349 Old Island Highway, Victoria B.C.

P.I.D. Numbers:

  • Lot 1, Plan 5985, Section 2, Esquimalt District 005-928-001
  • Lot 2, Plan 5985, Section 2, Esquimalt District 000-438-405
  • That Part of Section 92, in Plan 470R, Except Parts in Plan 6222, Esquimalt District 009-427-350
Site plan of proposed subdivision showing "Proposed Lots A-E, Bare Land Strata" and "Proposed Lot 1 Fee Simple Subdivision of Lot 2, Plan 5985". The plan indicates lot areas (Lot A: 345 m², Lot B: 390 m², Lot C: 413 m², Lot D: 629 m², Lot E: 464 m², and Lot 1: 700 m²), existing dwellings, an existing shop, and Easement 121739G (common property access). The site is bounded by Old Island Highway to the north and Prince Robert Drive to the southeast.
Site plan of proposed subdivision showing "Proposed Lots A-E, Bare Land Strata" and "Proposed Lot 1 Fee Simple Subdivision of Lot 2, Plan 5985". The plan indicates lot areas (Lot A: 345 m², Lot B: 390 m², Lot C: 413 m², Lot D: 629 m², Lot E: 464 m², and Lot 1: 700 m²), existing dwellings, an existing shop, and Easement 121739G (common property access). The site is bounded by Old Island Highway to the north and Prince Robert Drive to the southeast.

Plan Details and Disclaimers

  • All distances are in metres.
  • Lot dimensions derived from registered plans and not verified by this survey.
  • This document is for approval/discussion purposes only and not to be used for the reestablishment of property boundaries.
  • The signatory accepts no responsibility for any damages that may be suffered by a third party as a result of reproduction, transmission, or alteration to this document without consent of the signatory.
  • Note: Lot dimensions and areas are approximate, final lot dimensions and areas are to be finalized at time of legal survey.
  • Dwelling locations are from preliminary plan by R.J. Wey and Associates.
  • This plan is prepared from unchecked field data. Check measurements prior to construction.

Drawing: 11/05/09 File: 09-18327(Man).DWG Scale: 1:500

Michael Claxton Land Surveying Inc. B.C. & Canada Lands Surveyor Unit 80A 4223 Commerce Circle Victoria, B.C. V8Z-6N6 Phone: 250-479-2258 Fax: 250-479-3831 Email: surveys@hilbre.ca

© MICHAEL E. CLAXTON, B.C.L.S. 2009
