Appendix

Prince Robert Drive Streetscape

April 10, 2012Page 1101 section

Visual rendering of how the new development will look from the street level.

2. APPROVAL OF AGENDA
Strata Road streetscape

PRINCE ROBERT RIDGE

547 - 549 Island Highway for Hale / Gray / Porter / Davies Joint Venture
October 5, 2009

Prince Robert Drive Streetscape

Architectural rendering of the Prince Robert Drive Streetscape showing the landscape buffer, Strata Road connection, Lot 5, and Lot 6 on a sloping grade.
Architectural rendering of the Prince Robert Drive Streetscape showing the landscape buffer, Strata Road connection, Lot 5, and Lot 6 on a sloping grade.

Strata Road Streetscape

Lot 2 Building Details:

  • New roof
  • Existing shingles refurbished
  • New window casings
  • New trellises & pergolas

Lot 5 Building Details:

  • New trellises & pergola
  • New roof
  • New acrylic smooth stucco
  • New Hardipanel cladding

Lot 5 North Elevation

Page 110
Extracted from: 2012 04 10 Committee of the Whole Agenda
