Site Servicing Concept Plan

April 10, 2012Page 1181 section

Engineering diagram for water, sewer, and gas connections for the new lots.

2. APPROVAL OF AGENDA
November 4, 2009

PRINCE ROBERT RIDGE

SITE SERVICING CONCEPT PLAN - scale: 1:200m

Site servicing concept plan for Prince Robert Ridge, showing development of six lots situated between Island Highway and Prince Robert Drive. The plan identifies existing houses on Lots 2 and 5, proposed new houses on Lots 1, 3, 4, and 6, and details various utility connections including sanitary, storm, water, and hydro.
Site servicing concept plan for Prince Robert Ridge, showing development of six lots situated between Island Highway and Prince Robert Drive. The plan identifies existing houses on Lots 2 and 5, proposed new houses on Lots 1, 3, 4, and 6, and details various utility connections including sanitary, storm, water, and hydro.

LEGAL DESCRIPTION Lots 1 & 2, Section 92, Esquimalt District, Plan 5985, & Part in Plan 470R

LEGEND

  • EXISTING MANHOLE
  • EXISTING SANITARY SEWER
  • NEW SANITARY CONNECTION
  • EXISTING MANHOLE
  • EXISTING STORM SEWER
  • NEW STORM SEWER
  • EXISTING WATER SUPPLY
  • NEW WATER SUPPLY
  • NEW BC HYDRO/TELUS/SHAW
  • FUTURE GAS

547 - 549 Island Highway for Hale / Gray / Porter / Davies Joint Venture October 5, 2009 rev. Nov 4, 2009
