Landscape Plan (Attachment 4)

March 11, 2025Page 1161 section

Detailed landscape design plan showing outdoor amenity spaces, visitor bicycle parking, and site access for the Eltham & Helmcken project.

1 CALL TO ORDER
Lombard North GroupApril 18, 2022Victoria, B.C.Identifies 5 building blocks and common drive aisle

ELTHAM & HELMCKEN VICTORIA, B.C. LANDSCAPE PLAN

RE-ISSUED FOR DEVELOPMENT PERMIT: JULY 10, 2024 ISSUED FOR DEVELOPMENT PERMIT: MAY 13, 2022 DATE: APRIL 18, 2022 DWG NO.: EH-PRIOR SCALE: 1:200

REVISIONS

NO. DATE DESCRIPTION
1 FEB 02, 22 S.P. GENERAL/ EXISTING TREES
2 AUG 02, 22 S.P. PLOT EXPANSION
3 SEPT 14, 22 S.P. GENERAL
4 NOV 30, 22 S.P. GENERAL
5 DEC 08, 22 S.P. TREES
6 MAY 24, 23 UPDATED PER R.O.W. DATUM

LANDSCAPE PLAN

[Map: Main Landscape Plan showing buildings 1 through 5, parking stalls 1-20, site access from Eltham Road, and existing trees.]

Photo of a vehicle barrier gate.
Photo of a vehicle barrier gate.

Plan Details:

  • Site Access: Off Eltham Road.
  • Roads: Helmcken Road and Eltham Road.
  • Infrastructure: Drive Aisle, Visitor Bicycle Parking, Visitor Street Parking, Vehicle Barrier Gate.
  • Vegetation Notes:
    • Existing tree to be protected (Typ.)
    • Existing tree to be removed (Typ.)
    • 6m Sight Line Triangle (1.2m max growth height)
  • Building Grade Data:
    • BLDG 4 Avg. Grade: 84.61' / 25.79m
    • BLDG 5 Avg. Grade: 85.57' / 26.08m
    • BLDG 3 Avg. Grade: 85.39' / 26.03m
    • BLDG 2 Avg. Grade: 83.61' / 25.48m
    • BLDG 1 Avg. Grade: 84.17' / 25.66m

LEGEND

  • Medium Deciduous Tree: To be a selection of: Quercus palustris 'Tree Hedge' Pin Oak Autumn Gold. Size: 5 cm cal. Approximate No. - 04
  • Columnar Deciduous Tree: To be a selection of: Acer rubrum 'Red Winged', 'Armstrong' Red Maple. Size: 6.0 cm cal. Approximate No. - 07
  • Multi-Stem: To be a selection of: Star Magnolia (15% of trees). Size: 27 cm pot. Approximate No. - 02
  • Evergreen: To be a selection of: Pyramidal Columnar Taxus (BJ.). Size: 30 cm pot. Approximate No. - 279
  • Small Shrub: To be a selection of: Dwarf Boxwood (BJ.), Blueberry, Spirea, Pink, etc. Taxus (BJ.). Size: 30 cm pot. Approximate No. - 80
  • Vines: To be a selection of: Hydrangea anomala petiolaris. Size: 27 cm pot. Approximate No. - 05
  • Sedum Roof: To be a selection of: Pre-planted vegetation tile (or similar to Archo-Green). Size: Installed at 45 cm O.C.

NOTES

  1. Landscape areas are to be irrigated with a fully automatic underground irrigation system.
  2. This drawing is conceptual only and not intended for construction purposes.
  3. All landscape work and plant material shall conform to the most recent edition of the Canadian Landscape Standard.
  4. Refer to architectural for exterior furniture & lighting.
  5. Refer to arborist report & tree retention plan for management of existing trees.

ROOF AMENITY PLAN

[Map: Roof Amenity Plan showing individual outdoor amenity spaces for units 1 through 20.]

Amenity Space Sizes:

  • UNIT001: 30.19 m²
  • UNIT002: 42.01 m²
  • UNIT003: 50.57 m²
  • UNIT004: 43.08 m²
  • UNIT005: 43.44 m²
  • UNIT006: 43.62 m²
  • UNIT007: 38.95 m²
  • UNIT008: 41.39 m²
  • UNIT009: 32.06 m²
  • UNIT010: 40.8 m²
  • UNIT011: 41.5 m²
  • UNIT012: 41.49 m²
  • UNIT013: 43.02 m²
  • UNIT014: 47.41 m²
  • UNIT015: 47.41 m²
  • UNIT016: 47.06 m²
  • UNIT017: 50.37 m²
  • UNIT020: 49.87 m²

ROOF DETAIL PLAN

[Map: Enlarged Roof Detail Plan for Units 005, 006, 007, 008, and 009.]

Detail Measurements:

  • UNIT005 Stairs: 2.24 m²
  • UNIT006 Stairs: 2.00 m²
  • UNIT007 Stairs: 2.24 m²
  • UNIT008 Stairs: 2.24 m²
Page 116
