Visual details for the proposed exterior finishes, colors, and lighting fixtures for Phase 6.

9.3.3 a) Development Permit 2024-01 - 2001-2014 West Park Lane - Phase 6
Benjamin Moore colors used (e.g., Narragansett Green, Sea Haze)Dark-sky friendly exterior lighting fixtures specified

Color Sample Board

(all colors Benjamin Moore)

Scheme 1-Block U, R

  • Main Body-Narragansett Green HC-157, Templeton Gray HC 161, Cloud White CC-40
  • Trim-Cloud White CC-40
  • Fascia-Cloud White CC-40
  • Garage Door-Cloud White CC-40
  • Front Door-Cloud White CC-40
  • Rock-K2-Pacific Asher
Color swatches and textures for Scheme 1 and Scheme 2, including Benjamin Moore paint colors and Pacific Asher rock texture
Color swatches and textures for Scheme 1 and Scheme 2, including Benjamin Moore paint colors and Pacific Asher rock texture

Scheme 2-Blocks T, S, V

  • Main Body-Sea Haze 2137-50, Kendall Charcoal HC-166, Chelsea Gray HC-168, Flint AF-560
  • Trim-Cloud White CC-40
  • Fascia-Cloud White CC-40
  • Garage Door-Flint AF-560
  • Front Door-Cloud White CC-40
Site landscape plan showing Block R, Block S, Block T, Block U, and Block V with annotations for patios, lawns, fences, and artificial turf, including a front elevation rendering of Block U at the bottom
Site landscape plan showing Block R, Block S, Block T, Block U, and Block V with annotations for patios, lawns, fences, and artificial turf, including a front elevation rendering of Block U at the bottom

Block U

Page 178–183

Exterior Materials

Photo samples of exterior materials: James Hardie Plank, James Hardie Board and Batton, Northwest Door Therma Tech T-108 garage door, and Trim Lite flush glazed front door with satin etched glass
Photo samples of exterior materials: James Hardie Plank, James Hardie Board and Batton, Northwest Door Therma Tech T-108 garage door, and Trim Lite flush glazed front door with satin etched glass
  • Roof Shingles: Owen’s Corning, Duration, Onyx Black
  • Soffits, Gutters & Downspouts: Aluminum, Kaycan, Black
  • Flashings: Black
  • Fascia Boards: Combed Spruce, Wood Tone
  • Belly Bands: Combed Spruce, 2x12
  • Window Trim: Combed Spruce, Wood Tone, 1x4
  • Corner Boards: Combed Spruce, Wood Tone 1x4
  • Hardi Plank: Fibre Cement Plank, James Hardie (4 and 6 inch exposure)
  • Board and Batton: Fibre Cement Plank, James Hardie
  • Garage Doors (Painted): Steel, Northwest Doors
  • Front Posts: Combed Spruce, Wrapped
  • Rear Patio: Exposed Concrete, ICL, Gray
Page 178–183

Exterior Lighting

Placed around front door and garage

Photo of the WEST Outdoor Light fixture, a black lantern-style wall mount
Photo of the WEST Outdoor Light fixture, a black lantern-style wall mount

WEST Outdoor Light

  • -CAN IOL283-BK
  • -Black
  • -Outdoor 1 Light
  • -Watermark Glass
  • -100W Type A Bulb
  • -Down Light
