Drawing PR7 - PROPOSED ELEVATIONS BLDG A
Exterior architectural elevations for Building A showing material usage and rooflines.
ERSKINE MULTIFAMILY
PROPOSED ELEVATIONS BLDG A
FRONT ELEVATION
SIDE ELEVATION
- TOP OF ROOF: 44.43
- FIFTH FLOOR T.O.W.: 42.75
- FIFTH FLOOR T.O. PLY: 40.0
- FOURTH FLOOR T.O. PLY: 37.25
- THIRD FLOOR T.O. PLY: 34.5
- SECOND FLOOR T.O. PLY: 31.75
- MAIN FLOOR T.O. PLY: 29.0
- PROPERTY LINE: 29.0M
SIDE ELEVATION
- TOP OF ROOF: 44.43
- FIFTH FLOOR T.O.W.: 42.75
- FIFTH FLOOR T.O. PLY: 40.0
- FOURTH FLOOR T.O. PLY: 37.25
- THIRD FLOOR T.O. PLY: 34.5
- SECOND FLOOR T.O. PLY: 31.75
- MAIN FLOOR T.O. PLY: 29.0
REAR ELEVATION
- TOP OF ROOF: 44.43
- FIFTH FLOOR T.O.W.: 42.75
- FIFTH FLOOR T.O. PLY: 40.0
- FOURTH FLOOR T.O. PLY: 37.25
- THIRD FLOOR T.O. PLY: 34.5
- SECOND FLOOR T.O. PLY: 31.75
- MAIN FLOOR T.O. PLY: 29.0
MATERIAL LEGEND
SCALE: 1:128 METRIC
- FIBRE CEMENT PANELS: "IRON GREY" SMOOTH FINISH
- FIBRE CEMENT PANELS: "GREY SLATE" SMOOTH FINISH
- FIBRE CEMENT PANELS: "LIGHT MIST" SMOOTH FINISH
- WINDOW BOXES: FIBRE CEMENT LAPPED "CEDARTONE"
- ASPHALT SHINGLE ROOFING: "CHARCOAL GREY"
- VINYL WINDOWS - BLACK
- HANDRAILS, FASCIAS, DOWNSPOUTS, FLASHING PAINTED: BLACK
- ARCHITECTURAL CAST IN PLACE CONCRETE
- SOFFIT: CEDAR RENDITIONS IN 'TIMBERLINE'
REVISIONS
| NO. | DATE |
|---|---|
| ISSUED FOR REVIEW | JUL 07 2019 |
| ISSUED FOR REVIEW | AUG 13 2019 |
| ISSUED FOR REVIEW | OCT 23 2019 |
| ISSUED FOR REZONE | NOV 04 2019 |
| ISSUED FOR REZONE | JAN 23 2020 |
| ISSUED FOR REVIEW | MAR 09 2020 |
| ISSUED FOR REZONE | MAY 21 2020 |
| REISSUED FOR REZONE | AUG 06 2020 |
| UPDATED | NOV 25 2020 |
| ISSUED FOR DP | FEB 17 2021 |
| REISSUED FOR DP | MAR 24 2021 |
PROJECT INFORMATION
Tanis Frame Architect AIBC LEED AP 41289 Horizon Dr. Squamish BC V8B 0Y7 T: 250.650.7901 E: info@thujaarchitecture.ca
PROJECT: ERSKINE MULTIFAMILY DRAWING: PROPOSED ELEVATIONS BLDG A SCALE: AS NOTED PROJECT NO: 20-- DRAWN BY: TF/SW SHEET: PR7
NOTES
CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.
COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO. TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.
