Drawing PR8 - PROPOSED ELEVATIONS BLDG B

ERSKINE MULTIFAMILY

Architect: Tanis Frame Architect AIBC LEED AP 41289 Horizon Dr. Squamish BC V8B 0Y7 T: 250.650.7901 E: info@thujaarchitecture.ca

Project: ERSKINE MULTIFAMILY Drawing: PROPOSED ELEVATIONS BLDG B Sheet: PR8 Project No: 20-- Drawn By: TF/SW Scale: AS NOTED (1:128 METRIC)

General Notes

CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.

COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO. TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.

Revision History

NO.	DATE
ISSUED FOR REVIEW	JUL 07 2019
ISSUED FOR REVIEW	AUG 13 2019
ISSUED FOR REVIEW	OCT 23 2019
ISSUED FOR REZONE	NOV 04 2019
ISSUED FOR REZONE	JAN 23 2020
ISSUED FOR REVIEW	MAR 09 2020
ISSUED FOR REZONE	MAY 21 2020
REISSUED FOR REZONE	AUG 06 2020
UPDATED	NOV 25 2020
ISSUED FOR DP	FEB 17 2021
REISSUED FOR DP	MAR 24 2021

Material Legend

FIBRE CEMENT PANELS: "IRON GREY" SMOOTH FINISH
FIBRE CEMENT PANELS: "GREY SLATE" SMOOTH FINISH
FIBRE CEMENT PANELS: "LIGHT MIST" SMOOTH FINISH
WINDOW BOXES: FIBRE CEMENT LAPPED "CEDARTONE"
ASPHALT SHINGLE ROOFING: "CHARCOAL GREY"
VINYL WINDOWS - BLACK
HANDRAILS, FASCIAS, DOWNSPOUTS, FLASHING PAINTED: BLACK
ARCHITECTURAL CAST IN PLACE CONCRETE
SOFFIT: CEDAR RENDITIONS IN 'TIMBERLINE'

Elevations

Front Elevation

The front elevation shows a five-story building with a combination of fibre cement panels, window boxes, and balconies. Floor levels are indicated as:

TOP OF ROOF: 44.43
FIFTH FLOOR T.O.W.: 42.75
FIFTH FLOOR T.O. PLY: 40.0
FOURTH FLOOR T.O. PLY: 37.25
THIRD FLOOR T.O. PLY: 34.5
SECOND FLOOR T.O. PLY: 31.75
MAIN FLOOR T.O. PLY: 29.0
