Drawing PR9 - PROPOSED ELEVATIONS BLDG C
ERSKINE MULTIFAMILY
PROPOSED ELEVATIONS BLDG C
FRONT ELEVATION
Architectural drawing of the front facade of Building C, showing floor levels and material callouts.
SIDE ELEVATION
Architectural drawing of the side facade. Labels include "WATER EASEMENT" and "PROPERTY LINE".
SIDE ELEVATION
Architectural drawing of the opposite side facade. Label includes "PROPERTY LINE".
REAR ELEVATION
Architectural drawing of the rear facade of Building C. Label includes "PROPERTY LINE".
Floor Elevations
- TOP OF ROOF: 33.53
- FIFTH FLOOR T.O. WALL: 31.86
- FIFTH FLOOR T.O. PLY: 29.11
- FOURTH FLOOR T.O. PLY: 26.36
- THIRD FLOOR T.O. PLY: 23.81
- SECOND FLOOR T.O. PLY: 20.86
- MAIN FLOOR T.O. PLY: 18.11
Material Legend
| ID | Material |
|---|---|
| 1 | FIBRE CEMENT PANELS: "GREY SLATE" SMOOTH FINISH |
| 2 | FIBRE CEMENT PANELS: "IRON GREY" SMOOTH FINISH |
| 3 | FIBRE CEMENT PANELS: "LIGHT MIST" SMOOTH FINISH |
| 4 | FIBRE CEMENT LAPPED "CEDARTONE" |
| 5 | ASPHALT SHINGLE ROOFING: "CHARCOAL GREY" |
| 6 | VINYL WINDOWS - BLACK |
| 7 | HANDRAILS, FASCIAS, DOWNSPOUTS, FLASHING PAINTED: BLACK |
| 8 | ARCHITECTURAL CAST IN PLACE CONCRETE |
| 9 | SOFFIT: CEDAR RENDITIONS IN 'TIMBERLINE' |
Project Notes
CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.
COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO. TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.
Issuance History
| Description | Date |
|---|---|
| ISSUED FOR REVIEW | JUL 07 2019 |
| ISSUED FOR REVIEW | AUG 13 2019 |
| ISSUED FOR REVIEW | OCT 23 2019 |
| ISSUED FOR REZONE | NOV 04 2019 |
| ISSUED FOR REZONE | JAN 23 2020 |
| ISSUED FOR REVIEW | MAR 09 2020 |
| ISSUED FOR REZONE | MAY 21 2020 |
| REISSUED FOR REZONE | AUG 06 2020 |
| UPDATED | NOV 25 2020 |
| ISSUED FOR DP | FEB 17 2021 |
| REISSUED FOR DP | MAR 24 2021 |
Project Information
- Project: ERSKINE MULTIFAMILY
- Drawing: PROPOSED ELEVATIONS BLDG C
- Sheet Number: PR9
- Scale: AS NOTED (Graphic scale: 1:128 METRIC)
- Project No: 20--
- Date: FEB 17 2021
- Drawn By: TF/SW
- Architect: Tanis Frame Architect AIBC LEED AP, 41289 Horizon Dr. Squamish BC V8B 0Y7, T: 250.650.7901 E: info@thujaarchitecture.ca
