Drawing PR10 - PROPOSED ELEVATIONS BLDG D
ERSKINE MULTIFAMILY
PROPOSED ELEVATIONS BLDG D
Sheet: PR10
Architectural Information Tanis Frame Architect AIBC LEED AP THUJA architecture + design 41289 Horizon Dr. Squamish BC V8B 0Y7 T: 250.650.7901 E: info@thujaarchitecture.ca
Project Details
- Scale: AS NOTED (1:128 METRIC)
- Drawn By: TF/SW
- Date: MAR 24 2021
General Notes CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.
COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO. TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.
Revision History
| Description | Date |
|---|---|
| ISSUED FOR REVIEW | JUL 07 2019 |
| ISSUED FOR REVIEW | AUG 13 2019 |
| ISSUED FOR REVIEW | OCT 23 2019 |
| ISSUED FOR REZONE | NOV 04 2019 |
| ISSUED FOR REZONE | JAN 23 2020 |
| ISSUED FOR REVIEW | MAR 09 2020 |
| ISSUED FOR REZONE | MAY 21 2020 |
| REISSUED FOR REZONE | AUG 06 2020 |
| UPDATED | NOV 25 2020 |
| ISSUED FOR DP | FEB 17 2021 |
| REISSUED FOR DP | MAR 24 2021 |
Material Legend
- FIBRE CEMENT PANELS: "GREY SLATE" SMOOTH FINISH
- FIBRE CEMENT PANELS: "IRON GREY" SMOOTH FINISH
- FIBRE CEMENT PANELS: "LIGHT MIST" SMOOTH FINISH
- FIBRE CEMENT LAPPED "CEDARTONE"
- ASPHALT SHINGLE ROOFING: "CHARCOAL GREY"
- VINYL WINDOWS - BLACK
- HANDRAILS, FASCIAS, DOWNSPOUTS, FLASHING PAINTED: BLACK
- ARCHITECTURAL CAST IN PLACE CONCRETE
- SOFFIT: CEDAR RENDITIONS IN 'TIMBERLINE'
Elevations Overview The following elevations include various landscape elements as part of the visual representation:
Green deciduous tree
Coniferous evergreen tree
Pink flowering shrub
Red Japanese maple tree
Clump of tall grass
Watercolor-style deciduous tree rendering
Front Elevation
- Top of Roof: 33.53
- Fifth Floor T.O. Wall: 31.86
- Fifth Floor T.O. Ply: 29.11
- Fourth Floor T.O. Ply: 26.36
- Third Floor T.O. Ply: 23.81
- Second Floor T.O. Ply: 20.86
- Main Floor T.O. Ply: 18.11
Side Elevation (Left)
- Top of Roof: 33.53
- Fifth Floor T.O. Wall: 31.86
- Fifth Floor T.O. Ply: 29.11
- Fourth Floor T.O. Ply: 26.36
- Third Floor T.O. Ply: 23.81
- Second Floor T.O. Ply: 20.86
- Main Floor T.O. Ply: 18.11
Side Elevation (Right)
- Top of Roof: 33.53
- Fifth Floor T.O. Wall: 31.86
- Fifth Floor T.O. Ply: 29.11
- Fourth Floor T.O. Ply: 26.36
- Third Floor T.O. Ply: 23.81
- Second Floor T.O. Ply: 20.86
- Main Floor T.O. Ply: 18.11
Rear Elevation
- Top of Roof: 33.53
- Fifth Floor T.O. Wall: 31.86
- Fifth Floor T.O. Ply: 29.11
- Fourth Floor T.O. Ply: 26.36
- Third Floor T.O. Ply: 23.81
- Second Floor T.O. Ply: 20.86
- Main Floor T.O. Ply: 18.11
