Drawing PR11 - SITE SECTIONS
Cross-section drawings showing the relationship between buildings A, B, C, and D and the topography.
ERSKINE MULTIFAMILY
SITE SECTIONS
Project Information
| Project | ERSKINE MULTIFAMILY |
|---|---|
| Drawing | SITE SECTIONS |
| Scale | AS NOTED |
| Project No. | 20-- |
| Date | |
| Drawn By | TF/SW |
| Sheet | PR11 |
Revision History
| NO. | DATE |
|---|---|
| ISSUED FOR REVIEW | JUL 07 2019 |
| ISSUED FOR REVIEW | AUG 13 2019 |
| ISSUED FOR REVIEW | OCT 23 2019 |
| ISSUED FOR REZONE | NOV 04 2019 |
| ISSUED FOR REZONE | JAN 23 2020 |
| ISSUED FOR REVIEW | MAR 09 2020 |
| ISSUED FOR REZONE | MAY 21 2020 |
| REISSUED FOR REZONE | AUG 06 2020 |
| UPDATED | NOV 25 2020 |
| ISSUED FOR DP | FEB 17 2021 |
| REISSUED FOR DP | MAR 24 2021 |
Architect Information Tanis Frame Architect AIBC LEED AP 41289 Horizon Dr. Squamish BC V8B 0Y7 T: 250.650.7901 E: info@thujaarchitecture.ca
General Notes CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.
COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO. TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.
Drawing Content
KEY PLAN Scale: 1:1000 Metric The key plan illustrates the layout of Buildings A, B, C, and D on Lot A, situated between Watkiss Way and Erskine Lane. The plan includes annotations for Minimum Finished Elevations (MFE) as follows:
- Building A & B: 29.0M M.F.E.
- Building C & D: 18.11 M.F.E.
SITE SECTION A Scale: 1:384 A comprehensive site section showing Buildings A, B, C, and D. It details the grade changes across the property from Watkiss Way to the proposed building at 7 Erskine Lane.
- MFE of Building A & B: 29.0M
- MFE of Building C & D: 21.0M
- Rendering Elements included:
Deciduous tree with green leaves
Red Japanese maple tree
Tall, slender deciduous tree
Red car, side profile
Evergreen pine tree
SITE SECTION B Scale: 1:250 A section focusing on Building B and Building C, including underground parking details.
- MFE of Building B: 29.0M
- MFE of Building C: 21.0M
- Rendering Elements included:
Deciduous tree with green leaves
Red car, side profile
Evergreen pine tree
SITE SECTION C Scale: 1:250 A section through Building A and Building B along Erskine Lane.
- MFE of Building A: 29.0M
- Rendering Elements included:
Deciduous tree with green leaves
SITE SECTION D Scale: 1:250 A section through Building A relative to Watkiss Way and the property line.
- MFE of Building A: 29.0M
- Rendering Elements included:
SITE SECTION E Scale: 1:250 A section through Building A relative to Watkiss Way, showing landscaping and property lines.
- MFE of Building A: 29.0M
- Rendering Elements included:
