GRADE CALCULATIONS - 2820 Shoreline Dr
May 11, 2021Page 901 section
Table and diagram documenting natural and finished grade points for the site.
Drawing A5.2Average grade = 4.99 m
GRADE CALCULATIONS
2820 Shoreline Dr, View Royal
NATURAL & FINISHED GRADES
| POINT | ELEV (m) | AVG ELEV (m) | DIST (m) | AVG ELEV*DIST (sq.m) |
|---|---|---|---|---|
| A | 5.70 | |||
| B | 5.80 | 5.75 | 4.98 | 28.62 |
| C | 5.80 | 5.80 | 1.85 | 10.75 |
| D | 5.80 | 5.80 | 2.52 | 14.62 |
| E | 5.80 | 5.80 | 4.24 | 24.59 |
| F | 5.80 | 5.80 | 0.76 | 4.43 |
| G | 5.80 | 5.80 | 3.80 | 22.06 |
| H | 5.30 | 5.55 | 5.88 | 32.61 |
| J | 5.30 | 5.30 | 4.33 | 22.95 |
| K | 4.20 | 4.75 | 13.52 | 64.22 |
| L | 4.80 | 4.50 | 6.32 | 28.43 |
| M | 4.80 | 4.80 | 2.22 | 10.67 |
| N | 4.90 | 4.85 | 1.53 | 7.40 |
| O | 4.80 | 4.85 | 5.88 | 28.52 |
| P | 4.20 | 4.50 | 8.08 | 36.34 |
| Q | 4.8 | 4.50 | 6.42 | 28.91 |
| R | 4.9 | 4.85 | 3.40 | 16.47 |
| S | 4.7 | 4.80 | 3.84 | 18.41 |
| T | 4.7 | 4.70 | 1.15 | 5.40 |
| U | 4.8 | 4.75 | 3.13 | 14.85 |
| V | 4.8 | 4.80 | 0.51 | 2.43 |
| W | 4.9 | 4.85 | 4.35 | 21.07 |
| X | 4.7 | 4.80 | 1.95 | 9.36 |
| Y | 4.8 | 4.75 | 3.50 | 16.61 |
| 5.25 | 1.56 | 8.17 | ||
| TOTAL | 95.69 | 477.88 | ||
| AVG. GRADE (m) | 4.99 |
Revisions
- 4 MAR. 19, 2021 ISSUED FOR DP
- 3 FEB. 19, 2021 ISSUED FOR REVIEW
- 2 FEB. 1, 2021 ISSUED FOR REVIEW
- 1 JAN. 11, 2021 ISSUED FOR REVIEW
Project Information SPLYCE DESIGN BUILD INC 102-601 WEST HASTINGS STREET VANCOUVER, BC V6B 1M8 TEL: 604.733.0002 WWW.SPLYCE.CA
Project: 2820 Shoreline Dr, View Royal Drawing: GRADE CALCULATIONS Date: April 19 2021 Drawn By: mp Scale: as shown Sheet: A5.2
