SOUTH ELEVATION - Architectural Drawing

May 11, 2021Page 1161 section

Hand-drawn architectural elevation showing the south side of the proposed house and deck structure.

2. APPROVAL OF AGENDA (motion to approve)
17' 1" width marked6x6 post and retaining wall specified

South Elevation

Architectural drawing titled "SOUTH ELEVATION" showing the rear or side profile of a multi-story house. The drawing features a turret, balconies, a ground-level patio area, and various structural annotations.
Architectural drawing titled "SOUTH ELEVATION" showing the rear or side profile of a multi-story house. The drawing features a turret, balconies, a ground-level patio area, and various structural annotations.

Drawing Annotations and Notes

  • Structural Components:
    • 2x10 12" OC
    • 2-2x10"
    • 3-2x6"
    • 6x6 POST
  • New Installations:
    • NEW DOOR D1
    • NEW WINDOW W1
  • Site and Exterior Features:
    • RETAINING WALL
    • PATIO
    • RAISED LANDING
  • Dimensions:
    • 17' 1"
  • Detail References:
    • 2/4 (indicated within a circle)
Page 116
