DECK REPLACEMENT/ADDITION - Floor Plan

May 11, 2021Page 1171 section

Floor plan diagram detailing the proposed deck addition and replacement dimensions relative to the existing house.

2. APPROVAL OF AGENDA (motion to approve)
Proposed deck dimensions 14' 0" and 16' 0"Notes for existing sliding door and kitchen layout

Deck Replacement/Addition

Architectural floor plan showing the existing house layout including the dining room, kitchen, family room, and powder room, with a proposed deck replacement and addition including dimensions, stairs, and references to detail drawings.
Architectural floor plan showing the existing house layout including the dining room, kitchen, family room, and powder room, with a proposed deck replacement and addition including dimensions, stairs, and references to detail drawings.

Plan Details and Labels

  • Existing Interior Spaces:
    • D.R (Dining Room)
    • EXISTING KITCHEN
    • POWDER RM
    • EXISTING FAMILY ROOM
  • Proposed and Existing Exterior Features:
    • PROPOSED DECK
    • OUTLINE OF EXISTING DECK
    • EXISTING SLIDING DOOR
    • LINE OF ROOF OVER
    • DECK REPLACEMENT/ADDITION
  • Stairs and Section References:
    • UP (stair direction)
    • SEE STAIR DETAIL 2/4
    • SEE VINYL DECK DETAILS 4/4
    • SEE CROSS SECTION 1/4

Dimensions

  • Deck Dimensions:
    • 14' 0"
    • 16' 0"
    • 17' 1"
  • Stair and Landing Dimensions:
    • 4' 0" (stair width)
    • 4' 0" (landing depth)
  • Additional Plan Dimensions:
    • 1' 8"
    • 4' 0"
    • 5' 8"
