EAST ELEVATION - Architectural Drawing

May 11, 2021Page 1191 section

Hand-drawn architectural elevation showing the east side of the house with deck stairs and retaining wall.

2. APPROVAL OF AGENDA (motion to approve)
Scale: 1/4" = 1'0"

East Elevation

Architectural sketch of the east elevation of a building, featuring a multi-level structure with a deck, an external staircase leading down to a patio, and several windows.
Architectural sketch of the east elevation of a building, featuring a multi-level structure with a deck, an external staircase leading down to a patio, and several windows.

Scale: 1/4" = 1'0"

Labels and Notes:

  • NEW WINDOW (W2)
  • RETAINING WALL
  • PATIO
  • 4'
  • 4'
Page 119
