SITE PLAN - 2 Governors Point Rd

May 11, 2021Page 1211 section

Survey-style site plan showing the building footprint, existing deck, and the proposed deck replacement area.

2. APPROVAL OF AGENDA (motion to approve)
Scale: 1/16" = 1'0"Shows R1 setback of 7.46m

SITE PLAN

Scale: 1/16" = 1'-0"

Hand-drawn site plan for a property located on Governors Point Road. The plan shows the footprint of a building, an existing deck, and a "Proposed Deck". It includes a north arrow, property line measurements (31.42', 79.84', etc.), and identifies an R1 Setback of 24.6' adjacent to an area labeled "Park".
Hand-drawn site plan for a property located on Governors Point Road. The plan shows the footprint of a building, an existing deck, and a "Proposed Deck". It includes a north arrow, property line measurements (31.42', 79.84', etc.), and identifies an R1 Setback of 24.6' adjacent to an area labeled "Park".

Plan Details and Annotations:

  • Location: Governors Point Rd.
  • Building Information: Basement Floor Elevation 498.0
  • Setbacks: R1 Setback 24.6'
  • Adjacent Features: Park
  • Site Measurements:
    • 31.42'
    • 24.24'
    • 5.0'
    • 79.84'
    • 59.95'
    • 12'6"
    • 50.25'
    • 7.0'
    • 26.59'
    • 4.18'
    • 4.96'
