Site Plan Of: Lot 1, Section 98, Esquimalt District, Plan 21115

May 11, 2021Page 1851 section

A detailed site plan showing the proposed subdivision of Lot 1 on Atkins Road, including elevations and boundary lines.

2. APPROVAL OF AGENDA (motion to approve)
221 Atkins RoadSurveyed April 6, 2018Scale 1:250

Site Plan Of:

Lot 1, Section 98, Esquimalt District, Plan 21115. P.I.D. 003-483-991

Scale = 1:250

Dated this 6th day of April, 2018.

Distances and elevations shown are in metres. Elevations are based on an assumed datum.

This site plan is for building and design purposes and is for the exclusive use of our client. This document shows the relative location of the surveyed structures and features with respect to the boundaries of the parcel described above. This document shall not be used to define property lines or property corners.

Top portion of a detailed survey site plan showing Lot 2 and Lot 3 of Plan 31824.
Top portion of a detailed survey site plan showing Lot 2 and Lot 3 of Plan 31824.
Middle portion of the site plan showing Lot 1 (Area: 0.104 ha) and Lot 2 (Area: 0.113 ha) bordering Millstream and Atkins Road.
Middle portion of the site plan showing Lot 1 (Area: 0.104 ha) and Lot 2 (Area: 0.113 ha) bordering Millstream and Atkins Road.
Bottom portion of the site plan showing Lot 3 (Area: 0.134 ha), building details for No. 221, and the surveyor's contact information.
Bottom portion of the site plan showing Lot 3 (Area: 0.134 ha), building details for No. 221, and the surveyor's contact information.

The subject property is affected by the following registered documents: EV105849

Wey Mayenburg Land Surveying Inc. www.weysurveys.com #4-2227 James White Boulevard Sidney, BC V8L 1Z5 Telephone (250) 656-5155 File: 180095\SIT\LE
