Landscape Drawing L2/2 - Planting Plan
May 11, 2021Page 2371 section
Landscape planting plan and plant list for the residential development at 1938 West Park Lane.
Project: Thetis Lake ApartmentsDate: April 11, 2019Plant list includes 20 Sitka Spruce trees and various shrubs
THETIS LAKE APARTMENTS - 1938 WEST PARK LANE
[Diagram: Overall Planting Plan showing the building layout, surrounding roads, and specific planting locations keyed to the plant list.]
The plan includes the following areas and labels:
| KEY | BOTANICAL NAME | COMMON NAME | QTY | SIZE/SPACING & REMARKS |
|---|---|---|---|---|
| TREES | ||||
| ALA | AMELANCHIER LAEVIS 'SPRING FLURRY' | SPRING FLURRY SERVICEBERRY | 20 | 6cm CAL. |
| MSO | MAGNOLIA X SOULANGEANA | SAUCER MAGNOLIA | 8 | 6cm CAL. |
| PSI | PICEA SITCHENSIS | SITKA SPRUCE | 3 | 6cm CAL. |
| QGA | QUERCUS GARRYANA | GARRY OAK | 9 | 6cm CAL. |
| SHRUBS, PERENNIALS & GRASSES | ||||
| AMI | ACHILLEA MILLEFOLIUM 'SUMMER PASTELS' | SUMMER PASTELS YARROW | 33 | #01 CONT. / 0.6M O.C. SPACING |
| BSP | BLECHNUM SPICANT | DEER FERN | 25 | #01 CONT. / 0.6M O.C. SPACING |
| CRA | CAMPSIS RADICANS | TRUMPET VINE | 39 | #01 CONT. / 0.6M O.C. SPACING |
| CSE | CORNUS SERICEA 'FLAVIRAMEA' | YELLOW TWIG DOGWOOD | 15 | #01 CONT. / 1.5M O.C. SPACING |
| DCE | DESCHAMPSIA CESPITOSA | TUFTED HAIR GRASS | 36 | #01 CONT. / 1.0M O.C. SPACING |
| EAL | EUONYMUS ALATUS 'COMPACTA' | DWARF BURNING BUSH | 27 | #01 CONT. / 2.0M O.C. SPACING |
| FOR | FORSYTHIA 'NORTHERN GOLD' | NORTHERN GOLD FORSYTHIA | 5 | #01 CONT. / 2.0M O.C. SPACING |
| HEM | HEMEROCALLIS 'RUBY STELLA' | RUBY STELLA DAYLILY | 38 | #01 CONT. / 0.6M O.C. SPACING |
| HEU | HEUCHERA 'FROSTED VIOLET' | FROSTED VIOLET CORAL BELL | 25 | #01 CONT. / 0.75M O.C. SPACING |
| HOF | HOSTA 'FRANCEE' | FRANCEE HOSTA | 14 | #01 CONT. / 0.75M O.C. SPACING |
| HOS | HOSTA 'NORTHERN EXPOSURE' | NORTHERN EXPOSURE HOSTA | 19 | #01 CONT. / 1.5M O.C. SPACING |
| KFI | KNIPHOFIA 'FIRE DANCE' | FIRE DANCE RED HOT POKER | 67 | #01 CONT. / 0.75M O.C. SPACING |
| LVU | LEUCANTHEMUM VULGARE | OXEYE DAISY | 73 | #01 CONT. / 0.75M O.C. SPACING |
| PAL | PENNISETUM ALOPECUROIDES | FOUNTAIN GRASS | 25 | #01 CONT. / 1.0M O.C. SPACING |
| POR | PENNISETUM ORIENTALE 'KARLEY ROSE' | KARLEY ROSE FOUNTAIN GRASS | 19 | #01 CONT. / 1.0M O.C. SPACING |
| PLE | PHILADELPHUS LEWISII 'BLIZZARD' | WATERTON MOCKORANGE | 20 | #01 CONT. / 1.5M O.C. SPACING |
| RAL | RHODODENDRON ALBIFLORUM | WHITE RHODODENDRON | 48 | #01 CONT. / 1.5M O.C. SPACING |
| RSA | RIBES SANGUINEUM | RED-FLOWERING CURRANT | 8 | #01 CONT. / 1.5M O.C. SPACING |
| RNU | ROSA NUTKANA | NOOTKA ROSE | 16 | #01 CONT. / 2.0M O.C. SPACING |
| SDI | SALIX DISCOLOR | PUSSY WILLOW | 12 | #01 CONT. / 2.0M O.C. SPACING |
| SNI | SAMBUCUS NIGRA 'EVA' | BLACK LACE ELDERBERRY | 15 | #01 CONT. / 1.75M O.C. SPACING |
Planting Details
1 Shrub Planting (Typical) - Section
[Diagram: Sectional view of shrub planting detail showing root ball, pit dimensions, mulch, and soil saucer.]
- PRUNE DEAD & BROKEN BRANCHES - MAINTAIN NATURAL PLANT FORM
- FIRMLY COMPACTED EARTH SAUCER
- FINISHED GRADE
- 50mm MIN. DEPTH MULCH (REFER SPEC'S)
- REMOVE CONTAINER
- FIRMLY PACKED GROWING MEDIUM (REFER SPEC'S)
- PIT DIA. SHALL BE 2X THAT OF THE CONTAINER
2 Tree Planting in Mulch - Section
[Diagram: Sectional view of tree planting in mulch showing staking, guywires, root ball placement, and soil mix.]
- DIRECTION OF PREVAILING WIND
- 50mm MIN. DEPTH MULCH (REFER SPEC'S)
- FIRMLY COMPACTED GROWING MEDIUM (REFER SPEC'S)
- GUYWIRE - ATTACH NO. 11 GALVANIZED WIRE TO TREE USING STRAP, 20° WITH #4 GROMMET AROUND STEM ABOVE FIRST BRANCH (TYP. OF 2)
- CEDAR OR PRESSURE TREATED TIMBER STAKE - USE (2) 75MM DIA. X 2000mm HEIGHT STAKES. PLACE STAKE BEYOND THE EDGE OF THE ROOTBALL, ENSURE STAKES PENETRATE INTO A SOLID SUB-SOIL BASE. ORIENT STAKES TO BE PERPENDICULAR TO PREVAILING WIND.
- 50mm MIN. DEPTH EARTHEN SAUCER W/ MULCH. ROOTBALL / TRUNK FLARE NOT TO BE BURIED W/ GROWING MEDIUM OR MULCH
- CONTAINER GROWN SPECIMEN TREE PLANTED IN CENTER OF TREE PIT. REMOVE CONTAINER WHEN PLANTING
- TREE PIT EXCAVATED TO SPECIFICATION AND FILLED WITH APPROVED TOPSOIL/COMPOST MIX - 2 PARTS TOPSOIL, 1 PART COMPOST, BONEMEAL & FERTILIZER
3 Tree Planting in Turf - Section
[Diagram: Sectional view of tree planting in turf showing mulch ring, staking, guywires, and root ball placement.]
- DIRECTION OF PREVAILING WIND
- FIRMLY COMPACTED GROWING MEDIUM (REFER SPEC'S)
- GUYWIRE - ATTACH NO. 11 GALVANIZED WIRE TO TREE USING STRAP, 20° WITH #4 GROMMET AROUND STEM ABOVE FIRST BRANCH (TYP. OF 2)
- CEDAR OR PRESSURE TREATED TIMBER STAKE - USE (2) 75MM DIA. X 2000mm HEIGHT STAKES. PLACE STAKE BEYOND THE EDGE OF THE ROOTBALL, ENSURE STAKES PENETRATE INTO A SOLID SUB-SOIL BASE. ORIENT STAKES TO BE PERPENDICULAR TO PREVAILING WIND.
- REMOVE EXCESS SOIL & CIRCLING ROOTS FROM THE TOP OF THE ROOT BALL TO EXPOSE TRUNK FLARE
- 1000mm DIA. WOOD MULCH RING @ 50mm MIN. DEPTH
- CONTAINER GROWN SPECIMEN TREE PLANTED IN CENTER OF TREE PIT. REMOVE CONTAINER WHEN PLANTING
- TREE PIT EXCAVATED TO SPECIFICATION AND FILLED WITH APPROVED TOPSOIL/COMPOST MIX - 2 PARTS TOPSOIL, 1 PART COMPOST, BONEMEAL & FERTILIZER
Project Information
- Project Name: THETIS LAKE APARTMENTS
- Address: 1938 WEST PARK LANE
- Location: View Royal, BC
- Landscape Architect: OUTLAND DESIGN LANDSCAPE ARCHITECTURE
- Company Address: KLO Road, BC V1Y 7S2
- Phone:
- Website:
- Project No.: 19021
- Design By: NG
- Drawn By: NG
- Checked By: FB
- Date: APR 11, 2019
- Scale: 1:300
- Drawing Number: L2/2
FOR
| NO | DATE | REVISION |
|---|---|---|
| 1 | 19.03.21 | Review |
| 2 | 19.03.28 | Review |
| 3 | 19.04.11 | Review |
ISSUED FOR REVIEW ONLY Copyright Reserved. This drawing is the property of Outland Design Landscape Architecture and shall not be reproduced, resold, or redistributed without permission.
