Landscape Drawing L2/2 - Planting Plan (Revised)
May 11, 2021Page 2391 section
Revised landscape planting plan and plant list for Thetis Lake Apartments.
Project: Thetis Lake ApartmentsDate: Feb 18, 2021Plant list revised to include Garry Oak and Douglas Fir
PROJECT: THETIS LAKE APARTMENTS
1938 WEST PARK LANE View Royal, BC
ISSUED FOR / REVISION
| NO. | DATE | REVISION |
|---|---|---|
| 2 | 19.03.28 | Review |
| 3 | 19.04.11 | Review |
| 4 | 20.07.21 | Review |
| 5 | 20.08.10 | Review |
| 6 | 21.02.18 | As-Builts |
PROJECT INFORMATION
- PROJECT NO: 19021
- DESIGN BY: MD
- DRAWN BY: ND/WC
- CHECKED BY: FB
- DATE: FEB. 18, 2021
- SCALE: 1:300
- DRAWING NO: L2/2
PLANTING PLAN
[Main site plan diagram showing proposed landscape design for buildings, including specific plant placements along West Park Lane, Island Highway, and surrounding the building structures.]
PLANT LIST
| KEY | BOTANICAL NAME | COMMON NAME | QTY | SIZE/SPACING & REMARKS |
|---|---|---|---|---|
| TREES | ||||
| AFK | ACER TATARICUM 'JFS-KW2' | RUGGED CHARM MAPLE | 3 | 6cm CAL |
| ALA | AMELANCHIER LAEVIS 'SPRING FLURRY' | SPRING FLURRY SERVICEBERRY | 20 | 6cm CAL |
| MSO | MAGNOLIA X 'SOULANGEANA' | SAUCER MAGNOLIA | 7 | 6cm CAL |
| PSI | PICEA SITCHENSIS | SITKA SPRUCE | 2 | 6cm CAL |
| QGA | QUERCUS GARRYANA | GARRY OAK | 7 | 6cm CAL |
| SHRUBS, PERENNIALS & GRASSES | ||||
| AMY | ACHILLEA MILLEFOLIUM 'SUMMER PASTELS' | SUMMER PASTELS YARROW | 33 | #1 CONT./0.4M O.C. SPACING |
| AAL | AMELANCHIER ALNIFOLIA 'OBELISK' | STANDING OVATION SERVICEBERRY | 9 | #5 CONT./1.2M O.C. SPACING |
| BSP | BLECHNUM SPICANT | DEER FERN | 23 | #1 CONT./0.6M O.C. SPACING |
| CRA | CAMPSIS RADICANS | TRUMPET VINE | 39 | #2 CONT./1.0M O.C. SPACING |
| CSE | CORNUS SERICEA 'FLAVIRAMEA' | YELLOW TWIG DOGWOOD | 15 | #5 CONT./1.5M O.C. SPACING |
| DCE | DESCHAMPSIA CESPITOSA | TUFTED HAIR GRASS | 34 | #1 CONT./0.5M O.C. SPACING |
| EAL | EUONYMUS ALATUS 'COMPACTUS' | DWARF BURNING BUSH | 27 | #2 CONT./1.0M O.C. SPACING |
| FNG | FORSYTHIA 'NORTHERN GOLD' | NORTHERN GOLD FORSYTHIA | 5 | #5 CONT./1.5M O.C. SPACING |
| HEM | HEMEROCALLIS 'RUBY STELLA' | RUBY STELLA DAYLILY | 38 | #1 CONT./0.4M O.C. SPACING |
| HEU | HEUCHERA 'FROSTED VIOLET' | FROSTED VIOLET CORAL BELL | 35 | #1 CONT./0.4M O.C. SPACING |
| HOF | HOSTA 'FRANCEE' | FRANCEE HOSTA | 14 | #1 CONT./0.5M O.C. SPACING |
| HOS | HOSTA 'NORTHERN EXPOSURE' | NORTHERN EXPOSURE HOSTA | 19 | #1 CONT./0.5M O.C. SPACING |
| KFI | KNIPHOFIA 'FIRE DANCE' | FIRE DANCE RED HOT POKER | 67 | #1 CONT./0.75M O.C. SPACING |
| LVU | LEUCANTHEMUM VULGARE | OX-EYE DAISY | 47 | #1 CONT./0.75M O.C. SPACING |
| PAL | PENNISETUM ALOPECUROIDES | FOUNTAIN GRASS | 41 | #1 CONT./1.0M O.C. SPACING |
| POK | PENNISETUM ORIENTALE 'KARLEY ROSE' | KARLEY ROSE FOUNTAIN GRASS | 20 | #1 CONT./0.5M O.C. SPACING |
| PLE | PHILADELPHUS LEWISII 'BLIZZARD' | BLIZZARD MOCKORANGE | 20 | #5 CONT./1.5M O.C. SPACING |
| RAL | RHODODENDRON AURIFLORUM | WHITE RHODODENDRON | 48 | #5 CONT./1.5M O.C. SPACING |
| RSI | RIBES SANGUINEUM | RED-FLOWERING CURRANT | 8 | #5 CONT./1.5M O.C. SPACING |
| RNU | ROSA 'NOOTKANA' | NOOTKA ROSE | 16 | #2 CONT./1.0M O.C. SPACING |
| SGL | SALIX DISCOLOR | GLAUCOUS WILLOW | 12 | #2 CONT./1.0M O.C. SPACING |
| SNE | SAMBUCUS NIGRA 'EVA' | BLACK LACE ELDERBERRY | 15 | #5 CONT./1.5M O.C. SPACING |
PLANTING DETAILS
[Three section diagrams illustrating standard planting procedures for shrubs and trees.]
1. Shrub Planting (Typical) - Section
- Prune dead & broken branches - maintain natural plant form.
- 150mm min. depth rock mulch.
- Firmly compacted earth saucer.
- Finish grade.
- Firmly packed growing medium (refer specs).
- Remove container.
- Pit dia. shall be 2x that of the container.
2. Tree Planting in Mulch - Section
- NOTE: IRRIGATION TO TREES AS PER APPROVED IRRIGATION PLAN.
- CEDAR OR PRESSURE TREATED TIMBER STAKE - USE (2) 75mm DIA. X 2000mm HEIGHT STAKES. PLACE STAKE BEYOND THE EDGE OF THE ROOTBALL. ENSURE STAKES PENETRATE INTO A SOLID SUB-SOIL BASE. ORIENT STAKES TO BE PERPENDICULAR TO THE PREVAILING WIND.
- GUYWIRE - ATTACH NO. 11 GALVANIZED WIRE TO TREE SLING STRAP. 20" WITH #4 GROMMET AROUND STEM ABOVE FIRST BRANCH (TYP. OF 2).
- REMOVE EXCESS SOIL & CIRCLING ROOTS FROM THE TOP OF THE ROOT BALL TO EXPOSE TRUNK FLARE.
- 50mm MIN. DEPTH EARTHEN SAUCER W/ MULCH, ROOTBALL / TRUNK FLARE NOT TO BE FILLED W/ GROWING MEDIUM OR MULCH.
- FINISH GRADE.
- CONTAINER GROWN SPECIMEN TREE PLANTED IN CENTER OF TREE PIT. REMOVE CONTAINER WHEN PLANTING.
- TREE PIT EXCAVATED TO SPECIFICATION AND FILLED WITH APPROVED TOPSOIL/COMPOST MIX, PER SPECS.
- 1000mm width tree pit.
3. Tree Planting in Turf - Section
- GUYWIRE - ATTACH NO. 11 GALVANIZED WIRE TO TREE SLING STRAP. 20" WITH #4 GROMMET AROUND STEM ABOVE FIRST BRANCH (TYP. OF 2).
- CEDAR OR PRESSURE TREATED TIMBER STAKE - USE (2) 75mm DIA. X 2000mm HEIGHT STAKES. PLACE STAKE BEYOND THE EDGE OF THE ROOTBALL. ENSURE STAKES PENETRATE INTO A SOLID SUB-SOIL BASE. ORIENT STAKES TO BE PERPENDICULAR TO THE PREVAILING WIND.
- REMOVE EXCESS SOIL & CIRCLING ROOTS FROM THE TOP OF THE ROOT BALL TO EXPOSE TRUNK FLARE.
- 1000mm DIA. WOOD MULCH RING @ 50mm MIN. DEPTH.
- CONTAINER GROWN SPECIMEN TREE PLANTED IN CENTER OF TREE PIT. REMOVE CONTAINER WHEN PLANTING.
- TREE PIT EXCAVATED TO SPECIFICATION AND FILLED WITH APPROVED TOPSOIL/COMPOST MIX - 2 PARTS TOPSOIL, 1 PART COMPOST, BONE MEAL & FERTILIZER.
- Direction of prevailing wind.
- Firmly compacted growing medium (refer specs.).
- 1000mm width tree pit.
