Architectural Concepts: THETIS HEIGHTS PHASE 5

THETIS HEIGHTS

PHASE 5 - 6 STOREY

Drawing A10: Site Plan

**REM PARK** ±1.075 Ha. (20.7% OVERALL)

**Parking Access Ramp**

Proposed Phase 6 ±0.755 Ha. (2026)

Site Details:

• Parking ± 60 stalls - P1 ±30 Stalls P2
• Building Outline above
• Parking Access Ramp
• Elevations:
  • +75.00
  • +70.00
  • +65.00
  • +68.42
  • +60.00
  • +62.80 Lower P2
  • +65.80 Upper P1
• Tree Tops Elevations:
  • +95.00 TREE TOPS
  • +105.00 TREE TOPS
  • +90.00 TREE TOPS
• Dimensions: 14775, 5775, 7635

Drawing A11: Floor Plan - Level 1

• Open Site Space 70%
• Parking outline below
• Amenity Space
• Floor Plan Labels:
  • Amenity 207
  • LOBBY
  • Units: B, C 92, B 59, B, B, B, B, B, A 92, A
• Elevation: +68.80 LEVEL 1
• Site Plan context includes:
  • REM PARK ±1.075 Ha. (20.7% OVERALL)
  • Parking Access Ramp
  • Proposed Phase 6 buildings: [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]

Thetis Phase 5 Project Statistics

| Metric | Imperial | | :--- | :---: | :---: | | Site Area | 3895 | 41,927 | | Building Area | 1170 | 12,594 | | Cov’g % | 30% | 30% | | GFA | 7020 | 75,565 | | FAR | 1.80 | 1.80 |

Unit Breakdown

Drawing A12: Floor Plan - Levels 2 through 6

• Levels 2 through 6: 13 per floor
• Floor Plan Labels:
  • Units: A, A, B, B 59, B, B, C 92, D 104, B, B, B, B, A 92, A
• Elevations:
  • +71.80 LEVEL 2
  • +74.80 LEVEL 3
  • +77.80 LEVEL 4
  • +80.80 LEVEL 5
  • +83.80 LEVEL 6
  • +86.80 Roof
• Site Plan context includes:
  • REM PARK ±1.075 Ha. (20.7% OVERALL)
  • Proposed Phase 6 buildings: [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]

---

PHASE 5 - 10 STOREY

Drawing A0: Site Plan

REM PARK ±1.075 Ha. (20.7% OVERALL)

Proposed Phase 6 ±0.755 Ha. (2026) [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]

Site Details:

• Parking ± 60 stalls - P1 ±30 Stalls P2
• Building Outline above
• Parking Access Ramp
• Elevations: +75.00, +70.00, +65.00, +62.80 Lower P2, +65.80 Upper P1, +68.42, +60.00
• Tree Tops Elevations: +95.00, +105.00, +90.00
• Dimensions: 6800, 10183, 4785

Drawing A1: Floor Plan - Level 1

• Open Site Space 82%
• Surface parking and access / turnaround
• Parking outline below
• Amenity Space
• Elevation: +68.80 LEVEL 1
• Floor Plan Labels:
  • Amenity 184
  • LOBBY
  • Units: B, B 65, B, A, A 92
• Site Plan context includes:
  • REM PARK ±1.075 Ha. [Image 10]
  • Proposed Phase 6 buildings: [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]

Thetis Phase 5 Project Statistics

| Metric | Imperial | | :--- | :---: | :---: | | Site Area | 3895 | 41,927 | | Building Area | 715 | 7,696 | | Cov’g % | 18% | 18% | | GFA | 7150 | 76,964 | | FAR | 1.84 | 1.84 |

Unit Breakdown

Drawing A2: Floor Plan - Levels 2 through 7

• Levels 2 through 7 : 8 per floor
• Floor Plan Labels:
  • Units: A, A 92, B 65, B, A, A, B, B
• Elevations:
  • +71.80 LEVEL 2
  • +74.80 LEVEL 3
  • +77.80 LEVEL 4
  • +80.80 LEVEL 5
  • +83.80 LEVEL 6
  • +86.80 LEVEL 7
• Site Plan context context includes:
  • REM PARK ±1.075 Ha. [Image 10]
  • Proposed Phase 6 buildings: [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]

Drawing A3: Floor Plan - Level 8

• Level 8 : 6 suites
• Elevation: +89.80 LEVEL 8
• Floor Plan Labels:
  • Units: A, A 92, B 65, B, C, C 156
• Site Plan context includes:
  • REM PARK ±1.075 Ha. [Image 10]
  • Proposed Phase 6 buildings: [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]

Drawing A4: Floor Plan - Level 9 - 10

• Level 9 : 4 suites
• Elevations:
  • +92.80 LEVEL 9
  • +95.80 LEVEL 10
  • +98.80 ROOF
• Floor Plan Labels:
  • Units: C, C, C, C 156
• Site Plan context includes:
  • REM PARK ±1.075 Ha. [Image 10]
  • Proposed Phase 6 buildings: [Image 2], [Image 3], [Image 4], [Image 5], [Image 6], [Image 7], [Image 8], [Image 9], [Image 11], [Image 12], [Image 14], [Image 15], [Image 16], [Image 17], [Image 18], [Image 19], [Image 20], [Image 21], [Image 22]
