ERSKINE MULTIFAMILY SITE SECTIONS PR9
Additional architectural site section drawings (Sheet PR9) for the Erskine Multifamily project detailing specific slopes and adjacent building contexts.
ERSKINE MULTIFAMILY
Project Information
- Architect: Tanis Schulte, Architect AIBC, LEED AP, Thuja Architecture Studio
- Address: 41289 Horizon Dr. Squamish BC V8B 0Y7
- Contact: T: 250.650.7901 E: info@thujaarchitecture.ca
General Notes
CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.
COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO. TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.
Revisions
| NO. | DATE |
|---|---|
| ISSUED FOR REVIEW | JUL 07 2019 |
| ISSUED FOR REVIEW | AUG 13 2019 |
| ISSUED FOR REVIEW | OCT 23 2019 |
| ISSUED FOR REZONE | NOV 04 2019 |
| ISSUED FOR REZONE | JAN 23 2020 |
| ISSUED FOR REVIEW | MAR 09 2020 |
| ISSUED FOR REZONE | MAY 21 2020 |
| REISSUED FOR REZONE | AUG 06 2020 |
Site Drawings
Site Plan
Architectural site plan showing Building A, Building B, Building C, and Building D located on Lot A. The site is bounded by Watkiss Way and Erskine Lane. The plan indicates the locations for sections F, G, H, and J. Landscaping is represented by various tree types, including
SITE SECTION F
Scale: 1:250
Longitudinal architectural rendering of the proposed building elevation showing multiple stories and an underground parking level. A
SITE SECTION G
Scale: 1:250 Transverse architectural section showing the building's side profile and underground parking level with a . To the right, the "PROPOSED BUILDING 7 ERSKINE LANE" is shown in silhouette for context. Landscaping includes , , and .
SITE SECTION H
Scale: 1:250 Architectural section along Erskine Lane showing an 11.3% slope. The building elevation is visible in the background. Landscaping includes and .
SITE SECTION J
Scale: 1:250 Architectural section through the property line and Right of Way (R.O.W.) showing a 4.7% slope along Erskine Lane. Landscaping includes , , and .
Drawing Details:
- Project: ERSKINE MULTIFAMILY
- Drawing: SITE SECTIONS
- Sheet No: PR9
- Project No: 20--
- Scale: AS NOTED
- Drawn By: TS/SW
