ERSKINE MULTIFAMILY PROPOSED MATERIALS PR10
Material finish schedule (Sheet PR10) for the Erskine Multifamily project featuring concrete, fiber cement panels, and asphalt roofing samples.
ERSKINE MULTIFAMILY
PROPOSED MATERIALS
Material Samples:
- ARCHITECTURAL CAST IN PLACE CONCRETE
- FIBRE CEMENT PANELS "IRON GREY" SMOOTH FINISH
- WINDOW BOXES: FIBRE CEMENT LAP "CEDARTONE"
- FIBRE CEMENT PANELS "GREY SLATE" SMOOTH FINISH
- FIBRE CEMENT PANELS "LIGHT MIST" SMOOTH FINISH
- ASPHALT SHINGLE ROOFING "CHARCOAL GREY"
- HANDRAILS + FASCIAS PAINTED "BLACK"
