298 ISLAND HIGHWAY, VICTORIA, B.C. MIXED-USE - COMMERCIAL / RESIDENTIAL DEVELOPMENT (Architectural Drawings)

September 15, 2020Pages 699–72916 sections

Comprehensive set of architectural plans, including site plans, floor layouts, elevations, sections, and 3D representations for a 6-story mixed-use building.

June 17, 2020298 Island HighwayAnkenman Marchand Architects54 residential units total6-story building102 total parking stalls

298 Island Highway, Victoria, B.C.

Mixed-Use - Commercial / Residential Development

Issued for Rezoning - June 17, 2020


Page 699–729

Cover Page & Drawing List

Project No: 1938 Project: 298 Island Highway, Victoria, B.C. Owner: Jeffrey Sengara

Project Team:

  • Client: Royale Development Corp., 1151 West 32nd Avenue, Vancouver, BC, V6H 2H8. Contact: Jeffrey Sengara
  • Architect: Ankenman Marchand Architects, 1645 West 5th Avenue, Vancouver, BC V6J 1N5. Contact: Timothy Ankenman
  • Surveyor: Glen Mitchell Land Surveying Inc., 1030 North Park Street, Victoria, BC V8T 1C6. Contact: Glen Mitchell
  • Landscape: Lombard North Group, 836 Cormorant Street, Victoria, BC V8W 1R1. Contact: James Partlow
  • Traffic: ADDOZ Engineering Inc., 4128 Fraser Street, Vancouver, BC V5V 4E8. Contact: Emad Ealsaidi
Perspective rendering of the proposed mixed-use building at 298 Island Highway
Perspective rendering of the proposed mixed-use building at 298 Island Highway

Drawing List

Sheet Number Sheet Name
A001 COVER PAGE & DRAWING LIST
A002 STATISTICS
A030 CONTEXT
A040 STREETSCAPE
A041 STREETSCAPE
A050 BUILDING CODE DATA
A090 SHADOW STUDY
A100 SURVEY
A101 SITE PLAN
A105 PARKING LEVEL - P2 FLOOR PLAN
A107 PARKING LEVEL - P1 FLOOR PLAN
A110 GROUND FLOOR PLAN
A120 LEVEL 2 FLOOR PLAN
A130 LEVEL 3 FLOOR PLAN
A140 LEVEL 4 FLOOR PLAN
A150 LEVEL 5 FLOOR PLAN
A160 LEVEL 6 FLOOR PLAN
A170 ROOF PLAN
A200 ELEVATION - SOUTH
A210 ELEVATION - WEST
A220 ELEVATION - NORTH
A230 ELEVATION - EAST
A300 SECTION 1 - EAST & WEST - MAIN RAMP
A310 SECTION 2 - EAST & WEST - STAIR
A320 SECTION 3 - EAST & WEST
A330 SECTION 4 - NORTH & SOUTH - RAMP
A340 SECTION 5 - NORTH & SORTH
A600 3D REPRESENTATIONS
A610 3D REPRESENTATIONS
A810 AREAS - LEVEL 1
A820 AREAS - LEVEL 2

Submission and Revision History

  • Submission (2020-06-17): Issued for Rezoning
  • Revision 1 (2020-08-25): Revision per City comments

Page 699–729

Statistics

Legal Description: LOT 1, SECTION 8, ESQUIMALT DISTRICT, PLAN 35505. PID 000-348-554 Civic Address: 298 Island Highway, Victoria, BC Zoning: Current: C-1 (Community Commercial); Proposed: CD (Comprehensive Development - Mixed Use)

Development Data Summary

  • Site Area: 1,853.00 m² (19,945.53 SF)
  • Permitted FSR (Per C-1 = 0.8): 1,482.40 m² (15,956.42 SF)
  • Proposed Gross FSR (Proposed per CD = 3.0): 5,559.00 m² (59,836.58 SF)
  • Permitted Site Coverage (Per C-1 = 50%): 926.50 m²
  • Proposed Site Coverage (Proposed per CD = 75%): 1,391.00 m²
  • Height Permitted: 9 m
  • Height Proposed (per CD): 20.23 m (6 Storeys)

Setbacks

Description Required per C-1 Proposed per CD
Front lot line min. 7.5m 0m
Rear lot line min. 7.5m varies 3.12m to 3.95m
Side lot line min. 6m 0m
Flanking lot line min. 3m varies 3.12m to 4.33m

FSR Calculation Table

Table detailing FSR calculations for Levels 1 through 6, including floor area, circulation, amenities, and net floor area
Table detailing FSR calculations for Levels 1 through 6, including floor area, circulation, amenities, and net floor area

Parking Requirements (Per Table 5.2)

  • Residential:
    • Studio or One Bedroom (1 stall per unit): 16 units x 1 stall = 16 stalls
    • Two Bedroom (1.5 stalls per unit): 37 units x 1.5 stalls = 56 stalls
    • Three Bedroom or more (2 stalls per unit): 1 unit x 2 stalls = 2 stalls
    • Total residential stalls required: 74 stalls
  • Commercial (Retail store: 1 per 20m² of floor area): 559.3 m² / 20 m² = 28 stalls
  • TOTAL NUMBER OF STALLS REQUIRED: 102 stalls

Parking Proposed

  • Residential: 76 stalls (Total residential parking proposed)
  • Commercial: 28 stalls (Total commercial parking proposed)
  • TOTAL NUMBER OF STALLS PROPOSED: 104 stalls
    • Standard stalls total: 40 (40% allowable)
    • Small stalls total: 64 (60%)
    • Seeking relaxation on Standard vs. Small stalls ratio.

Bicycle Parking (Per Table 5.4)

  • Residential:
    • Class 1 (1 per dwelling unit): 54 units x 1 stall = 54 stalls (Class 1)
    • 6-stack rack per entrance (Class 2): six space rack = 1 Rack (Class 2)
    • Total Residential stalls proposed: 68 stalls (32 horizontal, 30 vertical, 6 Class 2)
  • Commercial:
    • Class 1 (1 per 250m²): 654.49 m² / 250 m² = 2.6 stalls (2 stalls Class 1, 6 stalls Class 2)
    • Total Commercial stalls proposed: 8 stalls
  • TOTAL NUMBER OF STALLS PROPOSED: 76 stalls

Unit Mix

Residential Units Breakdown

Unit Type Count
1 BDR 12
1 BDR + D 4
2 BDR 20
2 BDR + D 17
3 BDR 1
Total Residential Units 54

Commercial Units Breakdown

Unit Type Count
Commercial Units 1
Total Commercial Units 1

Page 699–729

Context

Aerial context photograph with the site at 298 Island Highway highlighted in white
Aerial context photograph with the site at 298 Island Highway highlighted in white

Page 699–729

Streetscape


Page 699–729

Building Code Data

Calculation of Sprinklered Bldg Exposing Bldg Face (BCBC 2018 Table 3.2.3.1.D)

East Elevation:

  • Limiting Distance: 3.31 m
  • Wall Area: 448.89 m²
  • Opening Area: 66.32 m²
  • Allowed %: 24.5%
  • Proposed %: 15%

North Elevation:

  • Limiting Distance: 6.3 m
  • Wall Area: 844.0 m²
  • Opening Area: 317.73 m²
  • Allowed %: 56.2%
  • Proposed %: 38%

Page 699–729

Shadow Study


Page 699–729

Survey

Topographic survey plan of the site prepared by Glen Mitchell Land Surveying Inc. dated January 13th, 2020
Topographic survey plan of the site prepared by Glen Mitchell Land Surveying Inc. dated January 13th, 2020

Page 699–729

Site Plan


Page 699–729

Parking Floor Plans


Page 699–729

Floor Plans (Levels 1-6)


Page 699–729

Roof Plan


Page 699–729

Elevations

Material Legend

  1. FIBRE CEMENT PANEL SYSTEMS. COLOR: LIGHT GREY.
  2. FIBRE CEMENT PANEL SYSTEMS. COLOR: DARK GREY.
  3. FIBRE CEMENT PANEL SYSTEMS. COLOR: WHITE.
  4. FIBRE CEMENT PANEL. COLOR: ASH, WOOD TEXTURE.
  5. FIBER CEMENT PANEL. COLOR: MAHOGANY, WOOD TEXTURE.
  6. FIBRE CEMENT PANEL SYSTEMS. COLOR: LIGHT BEIGE.
  7. FABRIC AWNING. COLOUR: RED.
  8. STOREFRONT GLASS & ALUMINIUM. COLOR: ALUMINUM.
  9. METAL & AND GLASS GUARD RAIL. COLOR: ALUMINUM.
  10. VINYL WINDOWS COLOR: CHARCOAL.
  11. CAST-IN-PLACE CONCRETE.
  12. ALUMINUM WINDOW. COLOR: CHARCOAL.
  13. METAL SUNSHADE. COLOR: ALUMINUM.
  14. WOOD & AND GLASS CANOPY.
  15. METAL AND GLASS CURTAIN WALL. COLOR: ALUMINUM.
  16. METAL AND GLASS CURTAIN WALL. COLOR: CHARCOAL.

Page 699–729

Building Sections


Page 699–729

3D Representations

3D perspective rendering from the street corner of Island Highway and Helmcken Road
3D perspective rendering from the street corner of Island Highway and Helmcken Road
3D perspective rendering of the building frontage along Island Highway
3D perspective rendering of the building frontage along Island Highway
3D perspective rendering showing the building side and rear elevation
3D perspective rendering showing the building side and rear elevation
3D perspective rendering focusing on the upper floor balconies and roofline
3D perspective rendering focusing on the upper floor balconies and roofline
Pedestrian level 3D rendering of the commercial street frontage and sidewalk
Pedestrian level 3D rendering of the commercial street frontage and sidewalk
Pedestrian level 3D rendering of a CRU entrance and outdoor seating area
Pedestrian level 3D rendering of a CRU entrance and outdoor seating area
Pedestrian level 3D rendering showing the relationship between the building and the sidewalk
Pedestrian level 3D rendering showing the relationship between the building and the sidewalk
Pedestrian level 3D rendering of the main commercial corner and building signage
Pedestrian level 3D rendering of the main commercial corner and building signage

Page 699–729

Area Plans

Level 1 Areas

Unit # Unit Type Area (m²) Area (SF)
- RESIDENTIAL LOBBY 65.7 m² 707.18 SF
- EXIT CORRIDOR 46.66 m² 502.29 SF
- EXIT STAIR 14.64 m² 157.57 SF
1 COMMERCIAL 559.31 m² 6020.4 SF
TOTAL 686.32 m² 7387.44 SF

Level 2 Areas

Unit # Unit Type Area (m²) Area (SF)
- RES. CIRCULATION 111.36 m² 1,198.7 SF
201 2 BDR + D 103.29 m² 1,111.76 SF
202 2 BDR 90.44 m² 973.49 SF
203 2 BDR 90.44 m² 973.49 SF
204 2 BDR 91.75 m² 987.6 SF
205 2 BDR 74.34 m² 800.23 SF
206 2 BDR + D 100.99 m² 1,087.02 SF
207 2 BDR + D 98.36 m² 1,058.69 SF
208 2 BDR + D 92.91 m² 1,000.08 SF
209 2 BDR + D 88.14 m² 948.74 SF
210 2 BDR 85.62 m² 921.58 SF
211 2 BDR 80.8 m² 869.75 SF
212 1 BDR 54.45 m² 586.14 SF
TOTAL 1,162.89 m² 12,517.27 SF
Page 699–729
